SPA项目开发之登陆注册

一，前置工作

1.1 在Eclipse中引入项目

1.2 出错解决

1.3 测试项目

this污染的问题可以通过箭头函数来实现 jdk8的 lambda表达

一，前置工作

1.1 在Eclipse中引入项目

选择Maven项目

找到需要引入的项目，等待引入成功，根据电脑性能不同引入时间也不同，在下载依赖，

1.2 出错解决

注意：如果引入后依赖出错可以尝试重新下载该依赖

解决办法：

1.找到报错依赖的本地仓库中的目录将他删除

2.重新下载

等待重新下载成功即可

1.3 测试项目

注意查看数据库账号密码是否正确

选中项目右键debug启动，提示整合成功

1.4 测试前端工程

在我们前端工程中的src的api action.js中可以看到绑定了后端的项目

测试访问一个地址（不需要传参），能否获取到数据库中的数据

访问地址：（成功）

数据库数据：

1.4 下载js依赖

在前端工程目录中输入cmd打开窗口输入指令

axios：前端向后台发送请求

npm install element-ui -S

qs：解决发送post请求代码冗余的问题

npm install axios -S

ElementUI:快速布局

npm install qs -S

vue-axios：将axios依赖整合进vue中

npm install vue-axios -S

如：

下载成功：

至此，前置工作完成！

二，用户登陆界面排版

2.1 引入main.js配置

import Vue from 'vue'
import ElementUI from 'element-ui' // 新添加 1
import 'element-ui/lib/theme-chalk/index.css' // 新添加 2 ，避免后期打包样式

Vue.use(ElementUI) //新增加 3 使用 ElementUI

main.js


// The Vue build version to load with the `import` command
// (runtime-only or standalone) has been set in webpack.base.conf with an alias.
import Vue from 'vue'
import ElementUI from 'element-ui' // 新添加 1
import 'element-ui/lib/theme-chalk/index.css' // 新添加 2 ，避免后期打包样式
import App from './App'
import router from './router'

Vue.use(ElementUI) //新增加 3
Vue.config.productionTip = false

/* eslint-disable no-new */
new Vue({
  el: '#app',
  router,
  components: { App },
  template: ''
})

从官网中添加表单样式代码进入Login.vue 将样式进行修改，达到我们想要的效果:


<template>
  <div class="login-wrap">
    <el-form :model="ruleForm" status-icon :rules="rules" ref="ruleForm" label-width="100px"
      class="demo-ruleForm login-container">
      <el-row>
        <el-col :span="24">
          <div style="text-align: center;" class="grid-content bg-purple">
            <h3>用户登陆h3>
          div>
        el-col>
      el-row>
      <el-form-item label="用户名" prop="uname">
        <el-input type="text" v-model="ruleForm.uname" autocomplete="off">el-input>
      el-form-item>
      <el-form-item label="密码" prop="pwd">
        <el-input type="password" v-model.number="ruleForm.pwd">el-input>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="24">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-button style="width: 100%;" type="primary" @click="submitForm">提交el-button>
            div>
          el-col>
        el-row>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="success" @click="">用户注册el-link>
            div>
          el-col>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="warning" @click="">忘记密码el-link>
            div>
          el-col>
        el-row>
      el-form-item>
    el-form>
  div>
template>

<script>
  export default {
    name: 'Login',
    data() {
      return {
        ruleForm: {}
      }
    },
    methods: {
      submitForm() {

      },
      resetForm() {

      }
    }
  }
script>

<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }

  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }

  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
style>

index.js


import Vue from 'vue'
import Router from 'vue-router'
import HelloWorld from '@/components/HelloWorld'
import Login from '@/views/Login'

Vue.use(Router)

export default new Router({
  routes: [
    {
      path: '/',
      name: 'Login',
      component: Login
    },
    {
      path: '/',
      name: 'Login',
      component: Login
    }
  ]
})

App.vue



<script>
export default {
  name: 'App'
}
script>

<style>
html,
body {
    width: 100%;
    height: 100%;
    box-sizing: border-box;
    padding: 0px;
    margin: 0px;
}
#app {
    font-family: "Avenir", Helvetica, Arial, sans-serif;
    -webkit-font-smoothing: antialiased;
    -moz-osx-font-smoothing: grayscale;
    color: #2c3e50;
    widows: 100%;
    height: 100%;
}
style>

main.js


// The Vue build version to load with the `import` command
// (runtime-only or standalone) has been set in webpack.base.conf with an alias.
import Vue from 'vue'
import ElementUI from 'element-ui' // 新添加 1
import 'element-ui/lib/theme-chalk/index.css' // 新添加 2 ，避免后期打包样式
import App from './App'
import router from './router'

Vue.use(ElementUI) //新增加 3
Vue.config.productionTip = false

/* eslint-disable no-new */
new Vue({
  el: '#app',
  router,
  components: { App },
  template: ''
})

页面运行效果：

用户登陆页面排版成功！

三，Vue之数据交互登录功能

this.$router.push(.....);

axios相当于jQuery中的ajax
作用：试用获取后台数据，做局部刷新
语法：
this.axios.post(url,this.param)
.then(function(resp){ })
.catch(function(error){ })

先添加一个用户注册页面，如果没有注册就可以跳转注册页面：

Reg.vue


<template>
  <div class="login-wrap">
    <el-form :model="ruleForm" status-icon  label-width="100px"
      class="demo-ruleForm login-container">
      <el-row>
        <el-col :span="24">
          <div style="text-align: center;" class="grid-content bg-purple">
            <h3>用户注册h3>
          div>
        el-col>
      el-row>
      <el-form-item label="用户名" prop="uname">
        <el-input type="text" v-model="ruleForm.uname" autocomplete="off">el-input>
      el-form-item>
      <el-form-item label="密码" prop="pwd">
        <el-input type="password" v-model.number="ruleForm.pwd">el-input>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="24">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-button style="width: 100%;" type="primary" @click="submitForm">提交el-button>
            div>
          el-col>
        el-row>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="success" @click="toLogin">用户登陆el-link>
            div>
          el-col>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="warning" @click="">忘记密码el-link>
            div>
          el-col>
        el-row>
      el-form-item>
    el-form>
  div>
template>

<script>
  export default {
    name: 'Reg',
    data() {
      return {
        ruleForm: {}
      }
    },
    methods: {
      submitForm() {

      },
      resetForm() {

      },
      toLogin() {
        this.$router.push({
          path:'/Login'
        })
      }
    }
  }
script>

<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }

  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }

  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
style>

在此登陆页面跳转到注册页面


<template>
  <div class="login-wrap">
    <el-form :model="ruleForm" status-icon  label-width="100px"
      class="demo-ruleForm login-container">
      <el-row>
        <el-col :span="24">
          <div style="text-align: center;" class="grid-content bg-purple">
            <h3>用户登陆h3>
          div>
        el-col>
      el-row>
      <el-form-item label="用户名" prop="uname">
        <el-input type="text" v-model="ruleForm.uname" autocomplete="off">el-input>
      el-form-item>
      <el-form-item label="密码" prop="pwd">
        <el-input type="password" v-model.number="ruleForm.pwd">el-input>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="24">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-button style="width: 100%;" type="primary" @click="submitForm">提交el-button>
            div>
          el-col>
        el-row>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="success" @click="toReg">用户注册el-link>
            div>
          el-col>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="warning" @click="">忘记密码el-link>
            div>
          el-col>
        el-row>
      el-form-item>
    el-form>
  div>
template>

<script>
  export default {
    name: 'Login',
    data() {
      return {
        ruleForm: {}
      }
    },
    methods: {
      submitForm() {

      },
      resetForm() {

      },
      toReg() {
        this.$router.push({path:'/Reg'})
      }
    }
  }
script>

<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }

  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }

  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
style>

index.js


import Vue from 'vue'
import Router from 'vue-router'
import HelloWorld from '@/components/HelloWorld'
import Login from '@/views/Login'
import Reg from '@/views/Reg'

Vue.use(Router)

export default new Router({
  routes: [
    {
      path: '/',
      name: 'Login',
      component: Login
    },
    {
      path: '/Login',
      name: 'Login',
      component: Login
    },
    {
      path: '/Reg',
      name: 'Reg',
      component: Reg
    }
  ]
})

vue项目对axios的全局配置

main.js


// The Vue build version to load with the `import` command
// (runtime-only or standalone) has been set in webpack.base.conf with an alias.
import Vue from 'vue'
import ElementUI from 'element-ui' // 新添加 1
import 'element-ui/lib/theme-chalk/index.css' // 新添加 2 ，避免后期打包样式
import App from './App'
import router from './router'
import axios from '@/api/http'  //#vue项目对axios的全局配置
import VueAxios from 'vue-axios'

Vue.use(ElementUI) //新增加 3
Vue.use(VueAxios,axios) //使用
Vue.config.productionTip = false

/* eslint-disable no-new */
new Vue({
  el: '#app',
  router,
  components: { App },
  template: ''
})

登陆提交方法的实现：


<template>
  <div class="login-wrap">
    <el-form :model="ruleForm" status-icon  label-width="100px"
      class="demo-ruleForm login-container">
      <el-row>
        <el-col :span="24">
          <div style="text-align: center;" class="grid-content bg-purple">
            <h3>用户登陆h3>
          div>
        el-col>
      el-row>
      <el-form-item label="用户名" prop="uname">
        <el-input type="text" v-model="ruleForm.uname" autocomplete="off">el-input>
      el-form-item>
      <el-form-item label="密码" prop="pwd">
        <el-input type="password" v-model.number="ruleForm.pwd">el-input>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="24">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-button style="width: 100%;" type="primary" @click="submitForm">提交el-button>
            div>
          el-col>
        el-row>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="success" @click="toReg">用户注册el-link>
            div>
          el-col>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="warning" @click="">忘记密码el-link>
            div>
          el-col>
        el-row>
      el-form-item>
    el-form>
  div>
template>

<script>
  export default {
    name: 'Login',
    data() {
      return {
        ruleForm: {}
      }
    },
    methods: {
      submitForm() {
        // $.post(url,function(){})
        // this.axios 找到的是 /api/http.js 文件
        // axios.urls = action --> this.axios.urls找到了 /api/action.js
        // action.js 是一个JSON对象，那么就可以取到请求的值
        let url = this.axios.urls.SYSTEM_USER_DOLOGIN;
        // alert(url);
        // {uname:'zs',pwd:'123'}
        this.axios.post(url,this.ruleForm)
        .then(function(resp){ //代表成功
          console.log(resp);
        }).catch(function(){ //代表失败

        });
      },
      resetForm() {

      },
      toReg() {
        this.$router.push({path:'/Reg'})
      }
    }
  }
script>

<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }

  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }

  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
style>

具体方法：

测试提交结果：

不输入内容时：

输入内容有误时

输入正确时：

以上就是我们的Vue之数据交互登录功能！

四，this指针污染

当我们登录时密码错误/密码正确/账户密码为空时，要出现相应的消息提示框，所以我们可去element官网上进行查找我们需要的提示框源代码：

this污染的问题可以通过箭头函数来实现 jdk8的 lambda表达


<template>
  <div class="login-wrap">
    <el-form :model="ruleForm" status-icon  label-width="100px"
      class="demo-ruleForm login-container">
      <el-row>
        <el-col :span="24">
          <div style="text-align: center;" class="grid-content bg-purple">
            <h3>用户登陆h3>
          div>
        el-col>
      el-row>
      <el-form-item label="用户名" prop="uname">
        <el-input type="text" v-model="ruleForm.uname" autocomplete="off">el-input>
      el-form-item>
      <el-form-item label="密码" prop="pwd">
        <el-input type="password" v-model.number="ruleForm.pwd">el-input>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="24">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-button style="width: 100%;" type="primary" @click="submitForm">提交el-button>
            div>
          el-col>
        el-row>
      el-form-item>
      <el-form-item>
        <el-row>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="success" @click="toReg">用户注册el-link>
            div>
          el-col>
          <el-col :span="12">
            <div style="text-align: center;" class="grid-content bg-purple">
              <el-link type="warning" @click="">忘记密码el-link>
            div>
          el-col>
        el-row>
      el-form-item>
    el-form>
  div>
template>

<script>
  export default {
    name: 'Login',
    data() {
      return {
        ruleForm: {}
      }
    },
    methods: {
      submitForm() {
        // $.post(url,function(){})
        // this.axios 找到的是 /api/http.js 文件
        // axios.urls = action --> this.axios.urls找到了 /api/action.js
        // action.js 是一个JSON对象，那么就可以取到请求的值
        let url = this.axios.urls.SYSTEM_USER_DOLOGIN;
        // alert(url);
        // {uname:'zs',pwd:'123'}
        this.axios.post(url,this.ruleForm)
        .then(resp => { //代表成功  this污染的问题可以通过箭头函数来实现 jdk8的 lambda表达式
          console.log(resp);
          if(resp.data.code == 1){
             //this指的是http.js
            this.$message({
              message:resp.data.msg,
              type:'success'
            });
          }else if (resp.data.code == 0){
            //this指的是http.js
            this.$message.error(resp.data.msg);
          }
        }).catch(function(){ //代表失败

        });
      },
      resetForm() {

      },
      toReg() {
        this.$router.push({path:'/Reg'})
      }
    }
  }
script>

<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }

  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }

  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
style>

效果展示：

不输入内容：

账号密码错误：

账号密码正确：

五，CORS跨域

解决cors跨域问题过滤器



	<filter>
		<filter-name>corsFilterfilter-name>
		<filter-class>com.zking.vue.util.CorsFilterfilter-class>
	filter>
	<filter-mapping>
		<filter-name>corsFilterfilter-name>
		<url-pattern>/*url-pattern>
	filter-mapping>

跨域问题：

跨域产生的因素：

协议+IP地址+端口+项目+...

协议、IP地址、端口、项目有任意一处发生改变都会产生跨域

配置tomcat允许跨域访问

CorsFilter


package com.zking.vue.util;

import java.io.IOException;

import javax.servlet.Filter;
import javax.servlet.FilterChain;
import javax.servlet.FilterConfig;
import javax.servlet.ServletException;
import javax.servlet.ServletRequest;
import javax.servlet.ServletResponse;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

/**
 * 配置tomcat允许跨域访问
 *
 * @author Administrator
 *
 */
public class CorsFilter implements Filter {

	@Override
	public void init(FilterConfig filterConfig) throws ServletException {
	}

	// @Override
	// public void doFilter(ServletRequest servletRequest, ServletResponse
	// servletResponse, FilterChain filterChain)
	// throws IOException, ServletException {
	// HttpServletResponse httpResponse = (HttpServletResponse) servletResponse;
	//
	// // Access-Control-Allow-Origin就是我们需要设置的域名
	// // Access-Control-Allow-Headers跨域允许包含的头。
	// // Access-Control-Allow-Methods是允许的请求方式
	// httpResponse.addHeader("Access-Control-Allow-Origin", "*");// *,任何域名
	// httpResponse.setHeader("Access-Control-Allow-Methods", "POST, GET, PUT,
	// DELETE");
	// // httpResponse.setHeader("Access-Control-Allow-Headers", "Origin,
	// // X-Requested-With, Content-Type, Accept");
	//
	// // 允许请求头Token
	// httpResponse.setHeader("Access-Control-Allow-Headers",
	// "Origin,X-Requested-With, Content-Type, Accept, Token");
	// HttpServletRequest req = (HttpServletRequest) servletRequest;
	// System.out.println("Token=" + req.getHeader("Token"));
	// if("OPTIONS".equals(req.getMethod())) {
	// return;
	// }
	//
	//
	// filterChain.doFilter(servletRequest, servletResponse);
	// }

	@Override
	public void doFilter(ServletRequest servletRequest, ServletResponse servletResponse, FilterChain filterChain)
			throws IOException, ServletException {
		HttpServletResponse resp = (HttpServletResponse) servletResponse;
		HttpServletRequest req = (HttpServletRequest) servletRequest;

		// Access-Control-Allow-Origin就是我们需要设置的域名
		// Access-Control-Allow-Headers跨域允许包含的头。
		// Access-Control-Allow-Methods是允许的请求方式
		resp.setHeader("Access-Control-Allow-Origin", "*");// *,任何域名
		resp.setHeader("Access-Control-Allow-Methods", "POST, GET, PUT, DELETE");
		// resp.setHeader("Access-Control-Allow-Headers", "Origin,X-Requested-With,
		// Content-Type, Accept");
		// 允许客户端，发一个新的请求头jwt
		resp.setHeader("Access-Control-Allow-Headers", "Origin,X-Requested-With, Content-Type, Accept, jwt");

		// 允许客户端，处理一个新的响应头jwt
		resp.setHeader("Access-Control-Expose-Headers", "jwt");
		// String sss = resp.getHeader("Access-Control-Expose-Headers");
		// System.out.println("sss=" + sss);

		// 允许请求头Token
		// httpResponse.setHeader("Access-Control-Allow-Headers","Origin,X-Requested-With,
		// Content-Type, Accept, Token");
		// System.out.println("Token=" + req.getHeader("Token"));

		if ("OPTIONS".equals(req.getMethod())) {// axios的ajax会发两次请求，第一次提交方式为：option，直接返回即可
			return;
		}
		filterChain.doFilter(servletRequest, servletResponse);
	}

	@Override
	public void destroy() {

	}
}

六，工具类的作用&get和post的区别

main.js


// The Vue build version to load with the `import` command
// (runtime-only or standalone) has been set in webpack.base.conf with an alias.
import Vue from 'vue'
import 'element-ui/lib/theme-chalk/index.css' // 新添加 2
import App from './App'
import router from './router'
import ElementUI from 'element-ui' // 新添加 1
// import axios from '@/api/http'
import axios from 'axios'
import VueAxios from 'vue-axios'

Vue.use(ElementUI)
Vue.use(VueAxios,axios)
Vue.config.productionTip = false

/* eslint-disable no-new */
new Vue({
  el: '#app',
  router,
  components: { App },
  template: ''
})

显示现象

post请求：


let url = 'http://localhost:8080/T216_SSH/vue/userAction_login.action';

   			this.axios.post(url, this.ruleForm).then(function(response) {
				console.log(response);
			}).catch(function(error) {
				console.log(error);
			});

axios、qs的作用

api/http.js：

1、将原生的json对象转换成字符串，通过拦截器转

2、将本项目中的所有接口地址，进行统一管理

相关阅读:
安装Android SDK点击SDK Manager.exe一闪而退完美解决方案
 智能隐形眼镜的研究进展与挑战
 基于javaweb的疫情物业系统(java+ssm+vue+elementui+mysql)
DDPG算法
 Python零基础速成班-第18讲-Python for Database MySQL数据库，Web Sever打造网页和API接口服务
 XML 外部实体 (XXE) 漏洞及其修复方法
 【数据结构与算法】队列的实现
 心理咨询预约微信小程序开发制作步骤
 什么是找出芯片bug的最好办法
 实战型开发--3/3，clean code
原文地址：https://blog.csdn.net/weixin_64313980/article/details/126802062
