【pm4py】process mining 读取log生成model/net/tree

Ref

【pm4py 官网】https://pm4py.fit.fraunhofer.de/
【ProM官网】http://promtools.org/doku.php

Quick Start

A sneak peak of pmp4y’s simple application:

import pm4py
log = pm4py.read_xes('')
process_model = pm4py.discover_bpmn_inductive(log)
pm4py.view_bpmn(process_model)
1
2
3
4

即读取XES log，基于inductive miner生成bpmn，并进行预览。例如：

1. 虚拟环境配置

• 创建虚拟环境：

virtualenv -p python3.7 ~/venv/processmining
source ~/venv/processminging/bin/activate
1
2

• 安装pm4py：

python3.7 -m pip install pm4py
1

pip list
1

pm4py为最新版本2.2.27

1. 读取log

可读取XES和CSV格式log：

1.1 读取XES格式log

pm4py.read_xes(log)

import pm4py
log = pm4py.read_xes('tests/input_data/running-example.xes')
1
2

此时可查看log，可看出log包含25个eventlog（即ProM中的cases），第一个eventlog包含92个traces（即Prom中第一个case包含92个event），第2个eventlog包含62个traces；这25个eventlog包含的traces数目最大为92，最小为34。

其中第一个eventlog的第一个trace（即ProM中第一个case的第一个event），concept:name为Start，lifecycle:transition为start……

下图即为ProM软件（【ProM官网】http://promtools.org/doku.php）对同一XES日志文件的读取分析数据，与pm4py相同。

xes_importer.apply(log)

除了pm4py官网上所显示的pm4py.read_xes('tests/input_data/running-example.xes')，还可以通过converter进行读取：

from pm4py.objects.log.importer.xes import importer as xes_importer
log = xes_importer.apply('')
1
2

1.2 读取CSV格式log

import pandas as pd
import pm4py

dataframe = pd.read_csv('tests/input_data/running-example.csv', sep=',')
dataframe = pm4py.format_dataframe(dataframe, case_id='case:concept:name', activity_key='concept:name', timestamp_key='time:timestamp')
event_log = pm4py.convert_to_event_log(dataframe)
1
2
3
4
5
6

要注意的是，表头应与case:concept:name, concept:name，time:timestamp对应；

但是当表格中有起始和终止时间时，未确定读取方法。（可在ProM中读取CSV，再转换为XES格式；然后即可通过1.1的方式读取）

2. miner

Process model - BPMN

process_model = pm4py.discover_bpmn_inductive(log)
1

Petri net

petri_net, initial_marking, final_marking = pm4py.discover_petri_net_inductive(log)
1

Process tree

process_tree = pm4py.discover_process_tree_inductive(log)
1

3. view

# BPMN
pm4py.view_bpmn(process_model_bpmn, format="pdf")

# Petri net
pm4py.view_petri_net(petri_net)

# Process tree
pm4py.view_process_tree(process_tree)
1
2
3
4
5
6
7
8

放大来看：
BPMN：

Petri net：

Process tree：

代码

#!/usr/bin/env python3
# -*- coding: utf-8 -*-

# @Time : 8/26/22 4:13 PM
# @Author :
# @File : processmining.py
# @Version :
# @Software: PyCharm
# @Description : 'process mining'

import pm4py
from pm4py.objects.log.importer.xes import importer as xes_importer

def quick_start():
    log = pm4py.read_xes('/home/deng/cugb/STL/CSTL/Process/PromEventLog/activitylog_uci_detailed_labour.xes')
    process_model = pm4py.discover_bpmn_inductive(log)
    pm4py.view_bpmn(process_model)

def read_xes():
    # read XES log
    # by pm4py.read_xes
    log = pm4py.read_xes('./PromEventLog/activitylog_uci_detailed_labour.xes')

    # by xes_importer.apply
    log = xes_importer.apply('./PromEventLog/activitylog_uci_detailed_labour.xes')
    log = xes_importer.apply('./PromEventLog/PurchasingExample_convertedByProM.xes')

    return log

def miner(log):
    # BPMN
    process_model_bpmn = pm4py.discover_bpmn_inductive(log)

    # Petri net
    petri_net, initial_marking, final_marking = pm4py.discover_petri_net_inductive(log)

    # Process tree
    process_tree = pm4py.discover_process_tree_inductive(log)

    return process_model_bpmn, petri_net, process_tree

def view(process_model_bpmn, petri_net, process_tree):
    # BPMN
    pm4py.view_bpmn(process_model_bpmn, format="pdf")
    pm4py.save_vis_bpmn(process_model_bpmn, 'test.pdf')

    # Petri net
    pm4py.view_petri_net(petri_net)

    # Process tree
    pm4py.view_process_tree(process_tree)

if __name__ == '__main__':
    quick_start()

    log = read_xes()
    process_model_bpmn, petri_net, process_tree = miner(log)
    view(process_model_bpmn, petri_net, process_tree)

    print('done')
