• NCCL源码解析⑦：机器间Channel连接


    作者｜KIDGINBROOK

    上节中完成了单机内部的channel搜索，仍然以ringGraph为例的话，相当于在单台机器内部搜索出来了一系列的环，接下来需要将机器之间的环连接起来。

    为了方便理解，假设两机十六卡的情况下第一台机器的一个ring为：

    1. graph->intra: GPU/0 GPU/7 GPU/6 GPU/3 GPU/2 GPU/5 GPU/4 GPU/1
    2. graph->inter: NET/0 NET/0

    第二个机器对应的ring为：

    1. graph->intra: GPU/10 GPU/9 GPU/8 GPU/13 GPU/12 GPU/15 GPU/14 GPU/11
    2. graph->inter: NET/0 NET/0

    allGather3Data用于rank间聚合channel的信息，ncclGraphInfo记录了环的信息，比如speed和type

    1. struct ncclGraphInfo {
    2.     int sameChannels;
    3.     float speedIntra;
    4.     float speedInter;
    5.     int typeIntra;
    6.   };
    7.
    8.   struct {
    9.     int cudaCompCap;
    10.     int fullCudaCompCap;
    11.     int nChannels;
    12.     struct ncclGraphInfo tree;
    13.     struct ncclGraphInfo ring;
    14.     struct ncclGraphInfo collNet;
    15.     struct ncclTopoRanks topoRanks;
    16.   } *allGather3Data;
    17.
    18.   NCCLCHECK(ncclCalloc(&allGather3Data, nranks));
    19.   allGather3Data[rank].cudaCompCap = ncclCudaCompCap();
    20.   allGather3Data[rank].nChannels = comm->nChannels = treeGraph.nChannels = ringGraph.nChannels =
    21.     std::min(treeGraph.nChannels, ringGraph.nChannels);
    22.   ...
    23.   allGather3Data[rank].ring.sameChannels = ringGraph.sameChannels;
    24.   allGather3Data[rank].ring.speedIntra = ringGraph.speedIntra;
    25.   allGather3Data[rank].ring.speedInter = ringGraph.speedInter;
    26.   allGather3Data[rank].ring.typeIntra = ringGraph.typeIntra;
    27.   ...

    然后开始设置ncclTopoRanks，获取当前rank在ring中的prev和next，其中第一个rank的prev和最后一个rank的next为-1，如rank6的prev为7，next为3；获取当前ring的ringRecv和ringSend，即ring的第一个节点和最后一个节点，最后将搜索到的环复制了一遍，这里在官方issue中看到相关解释是为了进一步的并行以充分利用带宽。

    1. struct ncclTopoRanks {
    2.   int ringRecv[MAXCHANNELS];
    3.   int ringSend[MAXCHANNELS];
    4.   int ringPrev[MAXCHANNELS];
    5.   int ringNext[MAXCHANNELS];
    6.   int treeUpRecv[MAXCHANNELS];
    7.   int treeUpSend[MAXCHANNELS];
    8.   int treeDnRecv[MAXCHANNELS];
    9.   int treeDnSend[MAXCHANNELS];
    10. };
    11.
    12. ncclResult_t ncclTopoPreset(struct ncclComm* comm,
    13.     struct ncclTopoGraph* treeGraph, struct ncclTopoGraph* ringGraph, struct ncclTopoGraph* collNetGraph,
    14.     struct ncclTopoRanks* topoRanks) {
    15.   int rank = comm->rank;
    16.   int localRanks = comm->localRanks;
    17.   int nChannels = comm->nChannels;
    18.
    19.   for (int c=0; c
    20.     struct ncclChannel* channel = comm->channels+c;
    21.     channel->ring.prev = channel->ring.next = -1;
    22.     ...
    23.
    24.     int* ringIntra = ringGraph->intra+c*localRanks;
    25.     int* treeIntra = treeGraph->intra+c*localRanks;
    26.     int* collNetIntra = collNetGraph->intra+c*localRanks;
    27.
    28.     for (int i=0; i
    29.       if (ringIntra[i] == rank) {
    30.         topoRanks->ringRecv[c] = ringIntra[0];
    31.         topoRanks->ringSend[c] = ringIntra[localRanks-1];
    32.         channel->ring.prev = (i == 0) ? -1 : ringIntra[i-1];
    33.         channel->ring.next = (i == localRanks-1) ? -1 : ringIntra[i+1];
    34.       }
    35.       ...
    36.     }
    37.     topoRanks->ringPrev[c] = channel->ring.prev;
    38.     topoRanks->ringNext[c] = channel->ring.next;
    39.   }
    40.   // Duplicate channels rings/trees
    41.   struct ncclChannel* channel0 = comm->channels;
    42.   struct ncclChannel* channel1 = channel0+nChannels;
    43.   memcpy(channel1, channel0, nChannels*sizeof(struct ncclChannel));
    44.   return ncclSuccess;
    45. }

    然后通过bootstrapAllGather获取全局的allGather3Data信息，计算出当前rank所在的node保存在comm->node，以及每个node的第一个rank保存在nodesFirstRank，因此例子中：

    1. nodesFirstRank[0]: 0
    2. nodesFirstRank[1]: 10

    然后开始将每个机器的环首尾相连组成大环。

    1. ncclResult_t ncclTopoPostset(struct ncclComm* comm, int* firstRanks, struct ncclTopoRanks** allTopoRanks, int* rings) {
    2.   // Gather data from all ranks
    3.   int *ringRecv, *ringSend, *ringPrev, *ringNext, *treeUpRecv, *treeUpSend, *treeDnRecv,*treeDnSend;
    4.   int nranks = comm->nRanks;
    5.   int nChannels = comm->nChannels;
    6.   NCCLCHECK(ncclCalloc(&ringRecv, nranks*MAXCHANNELS));
    7.   NCCLCHECK(ncclCalloc(&ringSend, nranks*MAXCHANNELS));
    8.   NCCLCHECK(ncclCalloc(&ringPrev, nranks*MAXCHANNELS));
    9.   NCCLCHECK(ncclCalloc(&ringNext, nranks*MAXCHANNELS));
    10.   NCCLCHECK(ncclCalloc(&treeUpRecv, nranks*MAXCHANNELS));
    11.   NCCLCHECK(ncclCalloc(&treeUpSend, nranks*MAXCHANNELS));
    12.   NCCLCHECK(ncclCalloc(&treeDnRecv, nranks*MAXCHANNELS));
    13.   NCCLCHECK(ncclCalloc(&treeDnSend, nranks*MAXCHANNELS));
    14.   for (int i=0; i<nranks; i++) {
    15.     for (int c=0; c<nChannels;c++) {
    16.       ringRecv[c*nranks+i] = allTopoRanks[i]->ringRecv[c];
    17.       ringSend[c*nranks+i] = allTopoRanks[i]->ringSend[c];
    18.       ringPrev[c*nranks+i] = allTopoRanks[i]->ringPrev[c];
    19.       ringNext[c*nranks+i] = allTopoRanks[i]->ringNext[c];
    20.       treeUpRecv[c*nranks+i] = allTopoRanks[i]->treeUpRecv[c];
    21.       treeUpSend[c*nranks+i] = allTopoRanks[i]->treeUpSend[c];
    22.       treeDnRecv[c*nranks+i] = allTopoRanks[i]->treeDnRecv[c];
    23.       treeDnSend[c*nranks+i] = allTopoRanks[i]->treeDnSend[c];
    24.     }
    25.   }
    26.
    27.   // Connect rings and trees. This should also duplicate the channels.
    28.   NCCLCHECK(connectRings(comm, ringRecv, ringSend, ringPrev, ringNext, firstRanks));
    29.   NCCLCHECK(connectTrees(comm, treeUpRecv, treeUpSend, treeDnRecv, treeDnSend, firstRanks));
    30.
    31.   // Duplicate ringPrev/ringNext for ncclBuildRing
    32.   memcpy(ringPrev+nChannels*nranks, ringPrev, nChannels*nranks*sizeof(int));
    33.   memcpy(ringNext+nChannels*nranks, ringNext, nChannels*nranks*sizeof(int));
    34.
    35.   // Duplication should be complete now
    36.   nChannels = comm->nChannels = std::min(MAXCHANNELS,nChannels*2);
    37.
    38.   // Honor NCCL_MIN_NRINGS/NCCL_MAX_NRINGS.
    39.   // We permit combining max, then min, to only use the first channels, then duplicate them.
    40.   nChannels = comm->nChannels = std::min((int)ncclMaxNchannels(), nChannels);
    41.   int c;
    42.   for (c=nChannels; c<ncclMinNchannels(); c++) {
    43.     memcpy(ringPrev+c*nranks, ringPrev+(c-nChannels)*nranks, nranks*sizeof(int));
    44.     memcpy(ringNext+c*nranks, ringNext+(c-nChannels)*nranks, nranks*sizeof(int));
    45.     memcpy(comm->channels+c, comm->channels+c-nChannels, sizeof(struct ncclChannel));
    46.   }
    47.   nChannels = comm->nChannels = c;
    48.
    49.   // Create rings array and check all is fine
    50.   NCCLCHECK(ncclBuildRings(nChannels, rings, comm->rank, comm->nRanks, ringPrev, ringNext));
    51.
    52.   free(ringRecv);
    53.   free(ringSend);
    54.   free(ringPrev);
    55.   free(ringNext);
    56.   free(treeUpRecv);
    57.   free(treeUpSend);
    58.   free(treeDnRecv);
    59.   free(treeDnSend);
    60.
    61.   return ncclSuccess;
    62. }

    这里将所有channel的prev，next，send，recv信息打平到数组中，例如recv[0]表示第一个ring中rank0的recv是哪个rank，然后开始计算当前机器第一个rank的prev和最后一个rank的next。

    1. static ncclResult_t connectRings(struct ncclComm* comm, int* ringRecv, int* ringSend, int* ringPrev, int* ringNext, int* firstRanks) {
    2.   int nChannels = comm->nChannels;
    3.   int nNodes = comm->nNodes;
    4.   for (int c=0; c
    5.     int* recv = ringRecv+c*comm->nRanks;
    6.     int* send = ringSend+c*comm->nRanks;
    7.     int* prev = ringPrev+c*comm->nRanks;
    8.     int* next = ringNext+c*comm->nRanks;
    9.     struct ncclChannel* channel0 = comm->channels+c;
    10.     struct ncclChannel* channel1 = channel0+nChannels;
    11.     for (int n=0; n
    12.       int recvRank = recv[firstRanks[n]];
    13.       int prevSendRank = send[firstRanks[(n-1+nNodes)%nNodes]];
    14.       prev[recvRank] = prevSendRank;
    15.       if (comm->rank == recvRank) {
    16.         channel0->ring.prev = prevSendRank;
    17.         channel1->ring.prev = prevSendRank;
    18.       }
    19.       int sendRank = send[firstRanks[n]];
    20.       int nextRecvRank = recv[firstRanks[(n+1)%nNodes]];
    21.       next[sendRank] = nextRecvRank;
    22.       if (comm->rank == sendRank) {
    23.         channel0->ring.next = nextRecvRank;
    24.         channel1->ring.next = nextRecvRank;
    25.       }
    26.     }
    27.     TRACE(NCCL_GRAPH, "Ring %d : %d -> %d -> %d", c, channel0->ring.prev, comm->rank, channel0->ring.next);
    28.     TRACE(NCCL_GRAPH, "Ring %d : %d -> %d -> %d", c+nChannels, channel1->ring.prev, comm->rank, channel1->ring.next);
    29.   }
    30.   return ncclSuccess;
    31. }

    如上所示，当前机器recv rank的prev就是前一个机器的send rank，当前机器send rank的next就是下一个机器的recv rank。然后执行ncclBuildRings按照大环的顺序依次记录rank到rings。

    1. ncclResult_t ncclBuildRings(int nrings, int* rings, int rank, int nranks, int* prev, int* next) {
    2.   for (int r=0; r
    3.     char prefix[30];
    4.
    5.     int current = rank;
    6.     for (int i=0; i
    7.       rings[r*nranks+i] = current;
    8.       current = next[r*nranks+current];
    9.     }
    10.     ...
    11.     // Check that all ranks are there
    12.     for (int i=0; i
    13.       int found = 0;
    14.       for (int j=0; j
    15.         if (rings[r*nranks+j] == i) {
    16.           found = 1;
    17.           break;
    18.         }
    19.       }
    20.       if (found == 0) {
    21.         WARN("Error : ring %d does not contain rank %d", r, i);
    22.         return ncclInternalError;
    23.       }
    24.     }
    25.   }
    26.   return ncclSuccess;
    27. }

    还是以上述为例，其中rank6记录的rings的第一个大环为：

    GPU/6 GPU/3 GPU/2 GPU/5 GPU/4 GPU/1 GPU/10 GPU/9 GPU/8 GPU/13 GPU/12 GPU/15 GPU/14 GPU/11 GPU/0 GPU/7

    到这里就完成了机器之间大环建立，每个rank都知道自己的上一个和下一个rank是谁，那么就可以建立实际的通信链路了。

    接下来每个rank都要为通信分配一些内存，为了提高性能，这里会在分配buffer之前设置cpu亲和性，使得分配的内存尽量是当前numa本地的。

    1. cpu_set_t affinitySave;
    2.   sched_getaffinity(0, sizeof(cpu_set_t), &affinitySave);
    3.   NCCLCHECK(ncclTopoSetAffinity(comm->topo, comm->rank));
    4.
    5. ncclResult_t ncclTopoSetAffinity(struct ncclTopoSystem* system, int rank) {
    6.   struct ncclTopoNode* cpu = NULL, *gpu = NULL;
    7.   for (int g=0; gnodes[GPU].count; g++) {
    8.     if (system->nodes[GPU].nodes[g].gpu.rank == rank) {
    9.       gpu = system->nodes[GPU].nodes+g;
    10.       // Find closer CPU
    11.       int cpuIndex = -1, minHops = 0;
    12.       for (int c=0; cnodes[CPU].count; c++) {
    13.         int nHops = system->nodes[GPU].nodes[g].paths[CPU][c].count;
    14.         if (cpuIndex == -1 || nHops < minHops) {
    15.           cpuIndex = c;
    16.           minHops = nHops;
    17.         }
    18.       }
    19.       cpu = system->nodes[CPU].nodes+cpuIndex;
    20.     }
    21.   }
    22.   if (cpu == NULL) {
    23.     WARN("Set CPU affinity : unable to find GPU/CPU for rank %d", rank);
    24.     return ncclInternalError;
    25.   }
    26.
    27.   // Query the CPU affinity set we were provided
    28.   cpu_set_t mask;
    29.   SYSCHECK(sched_getaffinity(0, sizeof(cpu_set_t), &mask), "sched_getaffinity");
    30.
    31.   // Get the affinity of the CPU close to our GPU.
    32.   cpu_set_t cpuMask = cpu->cpu.affinity;
    33.
    34.   cpu_set_t finalMask;
    35.   if (ncclParamIgnoreCpuAffinity())
    36.     // Ignore the CPU affinity set and use the GPU one instead
    37.     finalMask = cpuMask;
    38.   else
    39.     // Use a subset of the GPU affinity set
    40.     CPU_AND(&finalMask, &mask, &cpuMask);
    41.
    42.   // If there is a non empty set, use it to set affinity
    43.   if (CPU_COUNT(&finalMask)) {
    44.     char affinityStr[sizeof(cpu_set_t)*2];
    45.     NCCLCHECK(ncclCpusetToStr(&finalMask, affinityStr));
    46.     INFO(NCCL_INIT, "Setting affinity for GPU %d to %s", gpu->gpu.dev, affinityStr);
    47.     SYSCHECK(sched_setaffinity(0, sizeof(cpu_set_t), &finalMask), "sched_setaffinity");
    48.   }
    49.   return ncclSuccess;
    50. }

    首先获取当前线程的cpu亲和性保存到affinitySave，分配好buffer之后会用affinitySave来恢复亲和性。

    然后通过ncclTopoSetAffinity设置cpu亲和性，找到当前rank对应的cpu节点之后，可以获取到该cpu对应的core，即cpuMask，然后获取当前线程对应的亲和性，即mask，默认会取cpuMask和mask的交集finalMask，如果交集不为空的话，会将finalMask设置给当前线程。

    1. struct ncclConnect {
    2.   char data[CONNECT_SIZE];
    3. };
    4.
    5.   struct ncclConnect *connect;
    6.   NCCLCHECKGOTO(ncclCalloc(&connect, 2), ret, affinity_restore);
    7.   for (int c=0; cnChannels; c++) {
    8.     struct ncclChannel* channel = comm->channels+c;
    9.     NCCLCHECKGOTO(setupChannel(comm, c, rank, nranks, rings+c*nranks), ret, affinity_restore);
    10.     if (comm->nRanks == 1) continue;
    11.     NCCLCHECKGOTO(ncclTransportP2pSetup(comm, &ringGraph, channel, 1, &channel->ring.prev, 1, &channel->ring.next), ret, affinity_restore);
    12.     ...
    13.   }

    然后简单看下ncclChannel数据结构，其中collectives保存了用户向nccl提交的通信操作，比如ncclSend，ncclRecv等都会向collectives里加一项，ncclColl则保存了这些操作对应的参数；collectives是一个环形队列，所以collStart指向了开始位置，collCount表示队列中操作数量；FifoHead和FifoTail用于协调kernel产出数据和NET发送数据，其实就是生产者消费者，ncclPeer保存了通信相关的信息，后续再具体介绍。

    1. struct ncclRing {
    2.   // Shortcuts for userRanks[1] and userRanks[n-1]
    3.   int prev;  // 记录环中当前rank的上一个rank
    4.   int next;  // 记录环中当前rank的下一个rank
    5.
    6.   // Maps an internal nccl index to user-specified rank order. This is necessary
    7.   // since we need to know how the user expects data to be ordered across
    8.   // devices. Ordered from current device.
    9.   int* userRanks;  // 以当前rank为起点记录整个环
    10.   int* devUserRanks;  // device断的userRanks
    11. };
    12.
    13. struct ncclChannel {
    14.   union {
    15.     struct {
    16.       struct ncclRing ring;
    17.       struct ncclTree treeUp;
    18.       struct ncclTree treeDn;
    19.       struct ncclTree collTreeUp;
    20.       struct ncclTree collTreeDn;
    21.
    22.       int id;
    23.
    24.       // Communication structures
    25.       struct ncclPeer* peers;
    26.       struct ncclPeer* devPeers;
    27.
    28.       // Operation list for aggregation
    29.       struct ncclColl* collectives;
    30.       int collStart;
    31.       int collCount;
    32.       int collFifoHead; // Only used by GPU
    33.       int collFifoTail; // Only used by CPU
    34.     };
    35.     int data[0x80];
    36.   };
    37. };

    然后开始初始化channel，initChannel主要是buffer的分配，分配userRanks和devUserRanks，设置ncclPeer，分配collectives，因为host和device都会访问collectives这个数据结构，所以需要通过cudaHostAlloc分配host端的锁页内存，并通过flag cudaHostAllocMapped将其映射到cuda的地址空间。不过在uva系统上，cudaMallocHost，cudaHostAlloc + cudaHostAllocDefault以及cudaHostAlloc + cudaHostAllocMapped这三种方式没啥区别，host和device都可以访问。

    1. ncclResult_t initChannel(struct ncclComm* comm, int channelid) {
    2.   struct ncclChannel* channel = comm->channels+channelid;
    3.   if (channel->id != -1) return ncclSuccess;
    4.   channel->id = channelid;
    5.
    6.   // Ring index to user rank table.
    7.   NCCLCHECK(ncclCudaCalloc(&channel->ring.devUserRanks, comm->nRanks));
    8.   NCCLCHECK(ncclCalloc(&channel->ring.userRanks, comm->nRanks));
    9.
    10.   // Communication structures with peers.
    11.   NCCLCHECK(ncclCudaCalloc(&channel->devPeers, comm->nRanks+1)); // The extra one rank is for collnet root (i.e. network)
    12.   NCCLCHECK(ncclCalloc(&channel->peers, comm->nRanks+1));
    13.   for (size_t i=0; inRanks+1; ++i) {
    14.     channel->peers[i].send.comm = comm;
    15.     channel->peers[i].recv.comm = comm;
    16.   }
    17.
    18.   // Per-channel operation list.
    19.   NCCLCHECK(ncclCudaHostCalloc(&channel->collectives, NCCL_MAX_OPS));
    20.   return ncclSuccess;
    21. }
    22.
    23. template
    24. static ncclResult_t ncclCudaHostCalloc(T** ptr, size_t nelem) {
    25.   CUDACHECK(cudaHostAlloc(ptr, nelem*sizeof(T), cudaHostAllocMapped));
    26.   memset(*ptr, 0, nelem*sizeof(T));
    27.   return ncclSuccess;
    28. }

    然后从当前rank为起点，将环写到userRanks。

    1. static ncclResult_t setupChannel(struct ncclComm* comm, int channelId, int rank, int nranks, int* ringRanks) {
    2.   TRACE(NCCL_INIT, "rank %d nranks %d", rank, nranks);
    3.   NCCLCHECK(initChannel(comm, channelId));
    4.
    5.   struct ncclRing* ring = &comm->channels[channelId].ring;
    6.   // Reorganize ranks to start with rank.
    7.   int shift;
    8.   for (shift = 0; shiftshift++) {
    9.     if (ringRanks[shift] == rank) {
    10.       break;
    11.     }
    12.   }
    13.   for (int i=0; i
    14.     ring->userRanks[i] = ringRanks[(i+shift)%nranks];
    15.   }
    16.   return ncclSuccess;
    17. }

    然后执行ncclTransportP2pSetup建立当前rank和prev，next的通信链路。

    到这里就完成了机器之间channel的连接，下节会了解到通信链路的建立过程。

    （本文经授权后由OneFlow发布。原文：https://blog.csdn.net/KIDGIN7439/article/details/128144057）

    其他人都在看

    试用OneFlow: github.com/Oneflow-Inc/oneflow/


  • 相关阅读:
    基于Spring接口，集成Caffeine+Redis两级缓存
    【每日一题】最大矩形
    javaEE -9（7000字详解TCP/IP协议）
    异步 IO 机制 io_uring
    【Python机器学习】零基础掌握SpectralCoclustering聚类
    10.一键生成个人微信朋友圈数据电子书
    JDBC一般使用过程+两种statement的区别
    官网电子安全证书端口即将到期！新型诈骗短信！
    【线性代数】MIT Linear Algebra Lecture 2: Elimination with matrices
    武汉新时标文化传媒有限公司短视频用户规模达9.54亿
  • 原文地址：https://blog.csdn.net/OneFlow_Official/article/details/133191624
