package EventDrivenAndAnimation_Practice;

import java.util.ArrayList;
import java.util.Arrays;
import javafx.application.Application;
import javafx.geometry.Pos;
import javafx.scene.Scene;
import javafx.scene.control.Button;
import javafx.scene.image.Image;
import javafx.scene.image.ImageView;
import javafx.scene.layout.HBox;
import javafx.scene.layout.GridPane;
import javafx.scene.layout.HBox;
import javafx.scene.layout.BorderPane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.event.ActionEvent;
import javafx.event.EventHandler;

public class ShowFourCards extends Application {
	// 创建一个PokerPane
	private PorkerPane porkerPane = new PorkerPane();

	public void start(Stage primaryStage) {
		// 新建hbox用于存放button
		HBox hbox = new HBox();
		hbox.setSpacing(10);
		hbox.setAlignment(Pos.CENTER);

        //新建一个button
		Button btReflesh = new Button("Refresh");
		hbox.getChildren().add(btReflesh);

        //为reflesh按钮注册处理器
		btReflesh.setOnAction(new RefleshHandler());

	    //把hbox porkerpane放入面板
		BorderPane borderPane = new BorderPane();
		borderPane.setCenter(porkerPane);
		borderPane.setBottom(hbox);
		BorderPane.setAlignment(hbox, Pos.CENTER);

		Scene scene = new Scene(borderPane, 450, 200);
		primaryStage.setTitle("ShowFourCards");
		primaryStage.setScene(scene);
		primaryStage.show();
	}
    //定义一个名为 RefleshHandler的处理器类
	class RefleshHandler implements EventHandler {
		public void handle(ActionEvent e) {
			porkerPane.reflesh();
		}
	}
    //定义一个新的类PorkerPane用于显示扑克牌
	class PorkerPane extends GridPane {
		private Image ig1;
		private Image ig2;
		private Image ig3;
		private Image ig4;

		public PorkerPane() {

//			ig1 = ig2 = ig3 = ig4 = new Image("/porkerImage/53.jpg");
//
//			setHgap(5);
//			add(new ImageView(ig1), 0, 0);
//			add(new ImageView(ig2), 1, 0);
//			add(new ImageView(ig3), 2, 0);
//			add(new ImageView(ig4), 3, 0);
		}

		//提供reflesh方法用于显示随机的四张牌
		public void reflesh() {
			Integer array[] = new Integer[52];
			for (int i = 1; i <= 52; i++)
				array[i - 1] = i;
			ArrayList list = new ArrayList<>(Arrays.asList(array));
			java.util.Collections.shuffle(list);

			String url1 = "/porkerImage/" + list.get(0) + ".jpg";
			String url2 = "/porkerImage/" + list.get(1) + ".jpg";
			String url3 = "/porkerImage/" + list.get(2) + ".jpg";
			String url4 = "/porkerImage/" + list.get(3) + ".jpg";

			ig1 = new Image(url1);
			ig2 = new Image(url2);
			ig3 = new Image(url3);
			ig4 = new Image(url4);

			setHgap(5);
			add(new ImageView(ig1), 0, 0);
			add(new ImageView(ig2), 1, 0);
			add(new ImageView(ig3), 2, 0);
			add(new ImageView(ig4), 3, 0);
		}
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}
}

运行结果

2、旋转一个四边形

请写一个程序，在 Rotate 按钮被单击时，将一个四边形向右旋转15 度，如图所示

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.geometry.Pos;
import javafx.scene.Scene;
import javafx.scene.control.Button;
import javafx.scene.layout.HBox;
import javafx.scene.layout.StackPane;
import javafx.scene.layout.BorderPane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Rectangle;
import javafx.stage.Stage;
import javafx.event.ActionEvent;
import javafx.event.EventHandler;

public class RotateAQuadrilateral extends Application {

	private QuadrilateralPane quadrilateralPane = new QuadrilateralPane();

	public void start(Stage primaryStage) {
		HBox hbox = new HBox();
		hbox.setSpacing(10);
		hbox.setAlignment(Pos.CENTER);

		Button btRotate = new Button("Rotate");
		hbox.getChildren().add(btRotate);

		btRotate.setOnAction(new RotateHandler());

		BorderPane borderPane = new BorderPane();
		borderPane.setCenter(quadrilateralPane);
		borderPane.setBottom(hbox);
		BorderPane.setAlignment(hbox, Pos.CENTER);

		Scene scene = new Scene(borderPane, 200, 150);
		primaryStage.setTitle("RotateAQuadrilateral");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	class RotateHandler implements EventHandler {
		public void handle(ActionEvent e) {
			quadrilateralPane.rotate();
		}
	}

	class QuadrilateralPane extends StackPane {
		private Rectangle rectangle = new Rectangle(50, 80);

		public QuadrilateralPane() {
			getChildren().add(rectangle);
			rectangle.setStroke(Color.BLACK);
			rectangle.setFill(Color.GOLD);
		}

		public void rotate() {
			rectangle.setRotate(rectangle.getRotate() + 15);
		}
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

3、移动小球

编写一个程序，在面板上移动小球。应该定义一个面板类来显示小球，并提供向左、向右、向上和向下移动小球的方法，如图所示。请进行边界检査以防止球完全移到视线外。

问题分析：一开始把BallPane类定义成了

class BallPane extends StackPane

发现小球无法移动。改为

class BallPane extends Pane

程序正常运行

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.geometry.Pos;
import javafx.scene.Scene;
import javafx.scene.control.Button;
import javafx.scene.layout.HBox;
import javafx.scene.layout.Pane;
import javafx.scene.layout.BorderPane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.event.ActionEvent;
import javafx.event.EventHandler;

public class MoveBall extends Application {

	private BallPane ballPane = new BallPane();

	public void start(Stage primaryStage) {
		HBox hbox = new HBox();
		hbox.setSpacing(10);
		hbox.setAlignment(Pos.CENTER);

		Button btLeft = new Button("Left");
		Button btRight = new Button("Right");
		Button btUp = new Button("Up");
		Button btDown = new Button("Down");

		hbox.getChildren().addAll(btLeft, btRight, btUp, btDown);

		btLeft.setOnAction((ActionEvent e) -> {
			ballPane.left();
		});
		btRight.setOnAction((ActionEvent e) -> {
			ballPane.right();
		});
		btUp.setOnAction((ActionEvent e) -> {
			ballPane.up();
		});
		btDown.setOnAction((ActionEvent e) -> {
			ballPane.down();
		});

		BorderPane borderPane = new BorderPane();
		borderPane.setCenter(ballPane);
		borderPane.setBottom(hbox);
		BorderPane.setAlignment(hbox, Pos.CENTER);

		Scene scene = new Scene(borderPane, 500, 150);
		primaryStage.setTitle("MoveBall");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	// 定义BallPane用于放置小球
	class BallPane extends Pane {
		private Circle circle = new Circle(50,50,30);

		public BallPane() {
			getChildren().add(circle);
			circle.setStroke(Color.BLACK);
			circle.setFill(Color.GREY);
		}

		// 提供四个方法用于移动小球
		public void left() {
			circle.setCenterX(circle.getCenterX() > 10 ? circle.getCenterX() - 10 : 0);
		}

		public void right() {
			circle.setCenterX(circle.getCenterX() < this.getWidth() - 10 ? circle.getCenterX() + 10 : 0);
		}

		public void up() {
			circle.setCenterY(circle.getCenterY() > 10 ? circle.getCenterY() - 10 : 0);
		}

		public void down() {
			circle.setCenterY(circle.getCenterY() < this.getHeight() - 10 ? circle.getCenterY() + 10 : 0);
		}
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

4、创建一个簡单的计算器

编写一个程序完成加法、减法、乘法和除法操作

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.geometry.Pos;
import javafx.geometry.HPos;
import javafx.scene.Scene;
import javafx.scene.control.Button;
import javafx.scene.control.Label;
import javafx.scene.control.TextField;
import javafx.scene.layout.GridPane;
import javafx.scene.layout.HBox;
import javafx.scene.paint.Color;
import javafx.stage.Stage;

public class Calculator extends Application {
	private TextField tfNumber1 = new TextField();
	private TextField tfNumber2 = new TextField();
	private TextField tfResult = new TextField();

	private Button btAdd = new Button("Add");
	private Button btSubstract = new Button("Substract");
	private Button btMultiply = new Button("Multiply");
	private Button btDivide = new Button("Divide");

	public void start(Stage primaryStage) {
		GridPane pane = new GridPane();
		pane.setHgap(5);
		pane.setVgap(5);

		pane.add(new Label("Number1:"), 0, 0);
		pane.add(tfNumber1, 1, 0);
		pane.add(new Label("Number2:"), 0, 1);
		pane.add(tfNumber2, 1, 1);
		pane.add(new Label("Result"), 0, 2);
		pane.add(tfResult, 1, 2);

		pane.add(btAdd, 0, 3);
		pane.add(btSubstract, 1, 3);
		pane.add(btMultiply, 0, 4);
		pane.add(btDivide, 1, 4);

		pane.setAlignment(Pos.CENTER);
		tfNumber1.setAlignment(Pos.BOTTOM_RIGHT);
		tfNumber2.setAlignment(Pos.BOTTOM_RIGHT);
		tfResult.setAlignment(Pos.BOTTOM_RIGHT);

		btAdd.setOnAction(e -> add());
		btSubstract.setOnAction(e -> substract());
		btMultiply.setOnAction(e -> multiply());
		btDivide.setOnAction(e -> divide());

		Scene scene = new Scene(pane, 500, 500);
		primaryStage.setTitle("Calculator");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	private void add() {
		double number1 = Double.parseDouble(tfNumber1.getText());
		double number2 = Double.parseDouble(tfNumber1.getText());

		tfResult.setText(String.format("%.2f", number1 + number2));
	}

	private void substract() {
		double number1 = Double.parseDouble(tfNumber1.getText());
		double number2 = Double.parseDouble(tfNumber1.getText());

		tfResult.setText(String.format("%.2f", number1 - number2));
	}

	private void multiply() {
		double number1 = Double.parseDouble(tfNumber1.getText());
		double number2 = Double.parseDouble(tfNumber1.getText());

		tfResult.setText(String.format("%.2f", number1 * number2));
	}

	private void divide() {
		double number1 = Double.parseDouble(tfNumber1.getText());
		double number2 = Double.parseDouble(tfNumber1.getText());

		tfResult.setText(String.format("%.2f", number1 / number2));
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

5、两个消息交替出现

编写一个程序，当单击鼠标时，面板上交替显示两个文本 “ Java is

fun ” 和 “ Java i s powerful ”

代码


package EventDrivenAndAnimation_Practice;

import javafx.animation.Animation;
import javafx.animation.FadeTransition;
import javafx.animation.Timeline;
import javafx.animation.KeyFrame;
import javafx.event.*;
import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.image.ImageView;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Line;
import javafx.scene.text.Text;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;

public class AppearAlternately extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		Text text = new Text(20, 50, "Programming is fun");
		text.setFill(Color.RED);
		pane.getChildren().add(text);

		EventHandler eventHandler = e -> {
			if (text.getText() == "Programming is fun")
				text.setText("Programming is powerful");
			else
				text.setText("Programming is fun");
		};

		Timeline animation = new Timeline(new KeyFrame(Duration.millis(500), eventHandler));
		animation.setCycleCount(Timeline.INDEFINITE);
		animation.play();

		text.setOnMouseClicked(e -> {
			if (animation.getStatus() == Animation.Status.PAUSED)
				animation.play();
			else
				animation.pause();
		});
		Scene scene = new Scene(pane, 250, 200);
		primaryStage.setTitle("TimelineDemo");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

6、使用鼠标改变颜色

编写一个程序，显示一个圆的颜色，当按下鼠标键时颜色为黑色，释放鼠

标时颜色为白色

代码


package EventDrivenAndAnimation_Practice;

import javafx.animation.Animation;
import javafx.animation.FadeTransition;
import javafx.animation.Timeline;
import javafx.animation.KeyFrame;
import javafx.event.*;
import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.image.ImageView;
import javafx.scene.layout.StackPane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.scene.text.Text;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;

public class MouseClickChangeCircleColor extends Application {
	public void start(Stage primaryStage) {
		StackPane pane = new StackPane();

		Circle circle = new Circle(50);
		circle.setFill(Color.GRAY);
        pane.getChildren().add(circle);


		circle.setOnMouseClicked(e -> {
			if (circle.getFill() == Color.GRAY)
				circle.setFill(Color.BLACK);
			else
				circle.setFill(Color.GRAY);
		});
		Scene scene = new Scene(pane, 250, 200);
		primaryStage.setTitle("TimelineDemo");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

7、显示鼠标的位罝

编写两个程序，一个当单击鼠标时显示鼠标的位置.而另一个当按下鼠标时显示鼠标的位置，当释放鼠标时停止显示。

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class DisplayMousePositionWhenClicked extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();
		Text text = new Text();
		pane.getChildren().addAll(text);

		pane.setOnMouseClicked(e -> {
			text.setText("(" + e.getX() + "," + e.getY() + ")");
			text.setX(e.getX());
			text.setY(e.getY());
		});
		pane.setOnMouseReleased(event -> text.setText(""));

		Scene scene = new Scene(pane, 200, 200);
		primaryStage.setTitle("DisplayMousePositionWhenClicked");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class DisplayMousePositionWhenPressed extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();
		Text text = new Text();
		pane.getChildren().addAll(text);

		pane.setOnMousePressed(e -> {
			text.setText("(" + e.getX() + "," + e.getY() + ")");
			text.setX(e.getX());
			text.setY(e.getY());
		});
		pane.setOnMouseReleased(event -> text.setText(""));

		Scene scene = new Scene(pane, 200, 200);
		primaryStage.setTitle("DisplayMousePositionWhenClicked");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

8、使用箭头键画线

请编写一个程序，使用箭头键绘制线段。所画的线从面板的中心开始，当敲

击向右、向上、向左或向下的箭头键时，相应地向东、向北、向西或向南方向画线，如图所示

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.shape.Line;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class PaintLines extends Application {
	private double width = 400 / 2, height = 400 / 2;

	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		pane.setOnKeyPressed(e -> {
			switch (e.getCode()) {
			case DOWN:
				pane.getChildren().add(new Line(width, height, width, height + 50));
				height += 50;
				break;
			case UP:
				pane.getChildren().add(new Line(width, height, width, height - 50));
				height -= 50;
				break;
			case LEFT:
				pane.getChildren().add(new Line(width, height, width - 50, height));
				width -= 50;
				break;
			case RIGHT:
				pane.getChildren().add(new Line(width, height, width + 50, height));
				width += 50;
				break;
			}

		});

		Scene scene = new Scene(pane);
		primaryStage.setTitle("PaintLines");
		primaryStage.setScene(scene);
		primaryStage.show();

		pane.requestFocus();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

9、输入并显示字符串

请编写一个程序，从键盘接收一个宇符串并把它显示在面板上。回车键表明字符串结束。任何时候输人一个新宇符串时都会将它显示在面板上

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.input.KeyCode;
import javafx.scene.layout.StackPane;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class ShowString extends Application {
	public void start(Stage primaryStage) {
		StackPane pane = new StackPane();
		Text text = new Text("");

		pane.getChildren().add(text);

		text.setOnKeyPressed(e -> {
			text.setText(e.getCode() == KeyCode.ENTER ? "" : text.getText() + e.getText());
		});

		Scene scene = new Scene(pane, 500, 500);
		primaryStage.setTitle("ShowString");
		primaryStage.setScene(scene);
		primaryStage.show();

		text.requestFocus();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

10、使用键移动圓

请编写程序，可以使用箭头键向上、向下、向左、向右移动一个圆

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class MoveCircle extends Application {

	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		Circle circle = new Circle(100, 100, 50);
		circle.setFill(Color.GRAY);
		pane.getChildren().add(circle);

		circle.setOnKeyPressed(e -> {
			switch (e.getCode()) {
			case DOWN:
				circle.setCenterY(circle.getCenterY() + 20);
				break;
			case UP:
				circle.setCenterY(circle.getCenterY() - 20);
				break;
			case LEFT:
				circle.setCenterX(circle.getCenterX() - 20);
				break;
			case RIGHT:
				circle.setCenterX(circle.getCenterX() + 20);
				break;
			}
		});

		Scene scene = new Scene(pane, 400, 400);
		primaryStage.setTitle("MoveCircle");
		primaryStage.setScene(scene);
		primaryStage.show();

		circle.requestFocus();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

11、几何问題：添加或删除点

请编写一个程序，让用户在面板上单击以自动创建或移去点，当用户左击鼠标时（主按钮)，就创建一个点并且显示在鼠标的位置，用户还可以将鼠标移到一个点上，然后右击鼠标（次按钮）以移去这个点.

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.Node;
import javafx.scene.input.MouseButton;
import javafx.scene.layout.Pane;
import javafx.scene.shape.Circle;
import javafx.scene.paint.Color;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class AddOrDeleteDots extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		pane.setOnMouseClicked(e -> {
			Circle circle = new Circle(5);

			if (e.getButton() == MouseButton.PRIMARY) {
				circle.setFill(Color.WHITE);
				circle.setStroke(Color.BLACK);
				circle.setCenterX(e.getX());
				circle.setCenterY(e.getY());
				pane.getChildren().add(circle);
			} else
				for (Node node : pane.getChildren()) {
					Circle temp = (Circle) node;
					if (isInCircle(temp, e.getX(), e.getY())) {
						pane.getChildren().remove(temp);
						break;
					}
				}

		});
		Scene scene = new Scene(pane, 200, 200);
		primaryStage.setTitle("AddOrDeleteDots");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	private boolean isInCircle(Circle circle, double x, double y) {
		return Math.sqrt(Math.pow(x - circle.getCenterX(), 2) + Math.pow(y - circle.getCenterY(), 2)) <= circle
				.getRadius();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

12、两个可移动的顶点以及它们间的距离

请编写一个程序，显示两个分别位于（40,40)和（120,150) 的半径为10的圆，并用一条直线连接两个圆，如图所示。圆之间的距离显示在直线上。用户可以拖动圆，圆和它上面的直线会相应移动，并且两个圆之间的距离会更新

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.scene.shape.Line;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class TwoMovableCircles extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();
		Circle circle1 = new Circle(40, 40, 10);
		Circle circle2 = new Circle(120, 150, 10);

		circle1.setFill(Color.GRAY);
		circle2.setFill(Color.GRAY);

		Line line = new Line(40, 40, 120, 150);

		double x1 = circle1.getCenterX(), x2 = circle2.getCenterX();
		double y1 = circle1.getCenterY(), y2 = circle2.getCenterY();

		Text text = new Text((line.getStartX() + line.getEndX()) / 2, (line.getStartY() + line.getEndY()) / 2,
				distance(x1, x2, y1, y2) + "");

		pane.getChildren().addAll(circle1, circle2, line, text);

		circle1.setOnMouseDragged(e -> {
			circle1.setCenterX(e.getX());
			circle1.setCenterY(e.getY());
			line.setStartX(e.getX());
			line.setStartY(e.getY());

			double distance1 = distance(circle1.getCenterX(), circle2.getCenterX(), circle1.getCenterY(),
					circle2.getCenterY());

			text.setX((line.getStartX() + line.getEndX()) / 2);
			text.setY((line.getStartY() + line.getEndY()) / 2);
			text.setText(String.valueOf(distance1));

		});
		circle2.setOnMouseDragged(e -> {
			circle2.setCenterX(e.getX());
			circle2.setCenterY(e.getY());
			line.setEndX(e.getX());
			line.setEndY(e.getY());

			double distance2 = distance(circle1.getCenterX(), circle2.getCenterX(), circle1.getCenterY(),
					circle2.getCenterY());

			text.setX((line.getStartX() + line.getEndX()) / 2);
			text.setY((line.getStartY() + line.getEndY()) / 2);
			text.setText(String.valueOf(distance2));
		});
		Scene scene = new Scene(pane, 400, 400);
		primaryStage.setTitle("TwoMovableCircles");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public double distance(double x1, double x2, double y1, double y2) {
		double distance = Math.sqrt(Math.pow(x1 - x2, 2) + Math.pow(y1 - y2, 2));
		return distance;
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

13、几何问题：是否在圆内？

请编写一个程序，绘制一个圆心在（100, 60)而半径为 50的固定的圆。当鼠标移动时，显示一条消息表示鼠标点是在圆内还是在圆外，如图所示

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.scene.shape.Line;
import javafx.scene.text.Text;
import javafx.stage.Stage;

public class IsMouseInCircle extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();
		Circle circle = new Circle(100, 60, 50);
		circle.setFill(Color.PURPLE);

		Text text = new Text();
		pane.getChildren().addAll(circle, text);

		pane.setOnMouseMoved(e -> {
			double distance = Math.sqrt(Math.pow(e.getX() - 100, 2) + Math.pow(e.getY() - 60, 2));
			text.setX(e.getX());
			text.setY(e.getY());

			if (distance <= 50) {
				text.setText("Mouse point is inside the circle");
				text.setFill(Color.BLACK);
			}

			else {
				text.setText("Mouse point is not inside the circle");
				text.setFill(Color.RED);
			}

		});
		Scene scene = new Scene(pane, 300, 300);
		primaryStage.setTitle("IsMouseInCircle");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

14、几何问題：寻找边界矩形

请编写一个程序，让用户可以在一个二维面板上动态地增加和移除点，如图所示。当点加人和移除的时候，一个最小的边界矩形更新显示。假设每个点的半径是10像素

代码

问题分析：添加点实现了，但是删除点还实现不了......


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.Node;
import javafx.scene.input.MouseButton;
import javafx.scene.layout.Pane;
import javafx.scene.shape.Circle;
import javafx.scene.shape.Rectangle;
import javafx.scene.paint.Color;
import javafx.scene.text.Text;
import javafx.stage.Stage;
import java.util.ArrayList;
import java.util.Arrays;

public class FindingBoundary extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		Rectangle rectangle = new Rectangle();
		rectangle.setStroke(Color.BLACK);
		rectangle.setFill(Color.WHITE);
		rectangle.setOpacity(1);
		pane.getChildren().add(rectangle);

		ArrayList listX = new ArrayList<>();
		ArrayList listY = new ArrayList<>();

		pane.setOnMouseClicked(e -> {
			Circle circle = new Circle(5);

			if (e.getButton() == MouseButton.PRIMARY) {
				circle.setFill(Color.WHITE);
				circle.setStroke(Color.BLACK);
				circle.setCenterX(e.getX());
				circle.setCenterY(e.getY());
				pane.getChildren().add(circle);

				listX.add(e.getX());
				listY.add(e.getY());
				java.util.Collections.sort(listX);
				java.util.Collections.sort(listY);

				rectangle.setX(listX.get(0) - 5);
				rectangle.setY(listY.get(0) - 5);
				rectangle.setWidth(listX.get(listX.size() - 1) - listX.get(0) + 10);
				rectangle.setHeight(listY.get(listY.size() - 1) - listY.get(0) + 10);

			}
//				else {
//
//				for (Node node : pane.getChildren()) {
//
//					pane.getChildren().remove(rectangle);
//					Circle temp = (Circle) node;
//
//					if (isInCircle(temp, e.getX(), e.getY())) {
//						pane.getChildren().remove(temp);
//
//						listX.remove(e.getX());
//						listY.remove(e.getY());
//						java.util.Collections.sort(listX);
//						java.util.Collections.sort(listY);
//
//						rectangle.setStroke(Color.BLACK);
//						rectangle.setFill(Color.WHITE);
//
//						rectangle.setX(listX.get(0) - 5);
//						rectangle.setY(listY.get(0) - 5);
//						rectangle.setWidth(listX.get(listX.size() - 1) - listX.get(0) + 10);
//						rectangle.setHeight(listY.get(listY.size() - 1) - listY.get(0) + 10);
//						pane.getChildren().add(rectangle);
//						break;
//					}
//				}
//
//			}

		});
		Scene scene = new Scene(pane, 200, 200);
		primaryStage.setTitle("FindingBoundary");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	private boolean isInCircle(Circle circle, double x, double y) {
		return Math.sqrt(Math.pow(x - circle.getCenterX(), 2) + Math.pow(y - circle.getCenterY(), 2)) <= circle
				.getRadius();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

15、使用鼠标来移动一个矩形

请编写一个程序显示一个矩形。可以使用鼠标单击矩形内部并且拖动（即按住鼠标移动）矩形到鼠标的位置。鼠标点成为矩形的中央

代码


package EventDrivenAndAnimation_Practice;

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.text.Text;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;

public class MoveRectangleWithMouse extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();
		Circle circle = new Circle(50,50,30);
		circle.setStroke(Color.BLACK);
		circle.setFill(Color.GRAY);
		pane.getChildren().addAll(circle);

		circle.setOnMouseDragged(e -> {
			circle.setCenterX(e.getX());
			circle.setCenterY(e.getY());
		});
		Scene scene = new Scene(pane, 300, 300);
		primaryStage.setTitle("MouseEventDemo");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

16、游戏：手眼协调

请编写一个程序，显示一个半径为 10 像素的实心圆，该圆放置在面板上的

随机位置，并填充随机的顔色，如图所示。单击这个圆时，它会消失，然后在另一个随机的位置显示新的随机颜色的圆。在单击了 20 个圆之后，在面板上显示所用的时间，如图所示

代码


package EventDrivenAndAnimation_Practice;

import javafx.animation.Animation;
import javafx.animation.FadeTransition;
import javafx.animation.Timeline;
import javafx.animation.KeyFrame;
import javafx.event.*;
import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.image.ImageView;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.scene.text.Text;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;
import java.util.Date;

public class HandAndEyeCoordination extends Application {
	int count = 0;

	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		Circle circle = new Circle(Math.random() * 400, Math.random() * 400, 30);
		circle.setFill(new Color(Math.random(), Math.random(), Math.random(), Math.random()));
		pane.getChildren().add(circle);

		Date date1 = new Date(), date2;
		circle.setOnMouseClicked(e -> {
			count();
			circle.setCenterX(Math.random() * 400);
			circle.setCenterY(Math.random() * 400);
			circle.setFill(new Color(Math.random(), Math.random(), Math.random(), Math.random()));
			if (count == 5) {

				double time = new Date().getTime() - date1.getTime();
				Text text = new Text(50, 50, "Time spent is " + time + " milliseconds");
				text.setStroke(Color.BLACK);
				pane.getChildren().add(text);
			}

		});

		Scene scene = new Scene(pane, 400, 400);
		primaryStage.setTitle("HandAndEyeCoordination");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public void count() {
		count++;
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

17、动画：来回摆动

编写一个程序，用动画完成来回摆动，如图所示。单击 / 释放鼠标以暂停 / 恢复动画

代码

不足：实现的是长按暂停、释放停止。如果用setOnMouseClicked和setOnMouseReleased,只能实现暂停，暂未找到解决方法


package EventDrivenAndAnimation_Practice;

import javafx.animation.PathTransition;
import javafx.animation.Timeline;
import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Arc;
import javafx.scene.shape.ArcType;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;

public class SwingTheBall extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		Arc arc = new Arc(100, 100, 80, 80, -40, -100);
		arc.setStroke(Color.BLACK);
		arc.setFill(new Color(0, 0, 0, 0));
		arc.setType(ArcType.OPEN);

		Circle circle = new Circle(15);
//		circle.setStroke(Color.BLACK);
//		circle.setFill(Color.BLACK);

		pane.getChildren().addAll(circle, arc);

		PathTransition pt = new PathTransition();
		pt.setDuration(Duration.millis(5000));
		pt.setPath(arc);
		pt.setNode(circle);
		pt.setOrientation(PathTransition.OrientationType.ORTHOGONAL_TO_TANGENT);
		pt.setCycleCount(Timeline.INDEFINITE);
		pt.setAutoReverse(true);
		pt.play();

		pane.setOnMousePressed(e -> pt.pause());
		pane.setOnMouseReleased(e -> pt.play());

		Scene scene = new Scene(pane, 300, 300);
		primaryStage.setTitle("SwingTheBallo");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

18、动画：曲线上的球

请编写一个程序，用动画实现一个沿着正弦函数曲线移动的球，如图

所示。当球到达右边界时，它从左边重新开始。用户可以单击鼠标左 / 右按钮来继续 / 暂停动画

代码


package EventDrivenAndAnimation_Practice;
import javafx.application.Application;
import javafx.collections.ObservableList;
import javafx.geometry.Pos;
import javafx.scene.Scene;
import javafx.scene.input.MouseButton;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Circle;
import javafx.scene.shape.Line;
import javafx.scene.text.*;
import javafx.stage.Stage;
import javafx.util.Duration;
import javafx.scene.shape.Polyline;
import javafx.animation.PathTransition;
import javafx.animation.Timeline;

public class BallSwingAlongSineFunction extends Application{
	public void start(Stage primaryStage) {
		Pane pane = new Pane();
		Polyline polyline = new Polyline();
		pane.getChildren().add(polyline);

		polyline.setFill(Color.WHITE);
		polyline.setStroke(Color.PURPLE);
		ObservableList list = polyline.getPoints();

		for (double y = 0; y <= 1400; y++) {
			list.add(y);
			list.add(200 - 50 * Math.sin(Math.toRadians(y - 700)));
		}
		Line x = new Line(20, 200, 1500, 200);
		Line y = new Line(700, 600, 700, 10);
		x.setStrokeWidth(3);
		x.setStroke(Color.BLACK);
		pane.getChildren().add(x);

		y.setStrokeWidth(3);
		y.setStroke(Color.BLACK);
		pane.getChildren().add(y);

		Line arrowX1 = new Line(1480, 190, 1500, 200);
		Line arrowX2 = new Line(1480, 210, 1500, 200);
		arrowX1.setStroke(Color.BLACK);
		arrowX1.setStrokeWidth(3);
		arrowX2.setStroke(Color.BLACK);
		arrowX2.setStrokeWidth(3);

		Line arrowY1 = new Line(690, 30, 700, 10);
		Line arrowY2 = new Line(710, 30, 700, 10);
		arrowY1.setStroke(Color.BLACK);
		arrowY1.setStrokeWidth(3);
		arrowY2.setStroke(Color.BLACK);
		arrowY2.setStrokeWidth(3);

		Text t1 = new Text(1480, 220, "x");
		t1.setFont((Font.font("Times Nre Roman", FontWeight.BOLD, FontPosture.ITALIC, 25)));
		Text t2 = new Text(710, 8, "y");
		t2.setFont((Font.font("Times Nre Roman", FontWeight.BOLD, FontPosture.ITALIC, 25)));
		pane.getChildren().addAll(arrowX1, arrowX2, arrowY1, arrowY2, t1, t2);


		Circle circle = new Circle(15);
		pane.getChildren().add(circle);

		PathTransition pt = new PathTransition();
		pt.setDuration(Duration.millis(5000));
		pt.setPath(polyline);
		pt.setNode(circle);
		pt.setOrientation(PathTransition.OrientationType.ORTHOGONAL_TO_TANGENT);
		pt.setCycleCount(Timeline.INDEFINITE);
		pt.setAutoReverse(true);
		pt.play();

		pane.setOnMousePressed(e -> {
			if(e.getButton() == MouseButton.PRIMARY)
				pt.pause();
			else
				pt.play();
		});

		Scene scene = new Scene(pane, 1600, 450);
		primaryStage.setTitle("BallSwingAlongSineFunction");
		primaryStage.setScene(scene);
		primaryStage.show();
	}
	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

19、改变透明度

重写上一道, 当球摆动的时候改变球的透明度

只需要在原代码基础上加


FadeTransition ft = new FadeTransition(Duration.millis(5000),circle);
		ft.setFromValue(1.0);
		ft.setToValue(0.1);
		ft.setCycleCount(Timeline.INDEFINITE);
		ft.setAutoReverse(true);
		ft.play();

		circle.setOnMousePressed(e->ft.pause());
		circle.setOnMouseReleased(e->ft.play());

20、控制一个移动的文本

请编写一个程序，显示一个移动的文本，如图所示。文本从左到右循环的移动。当它消失在右侧的时候，又会从左侧再次出现。当鼠标按下的时候，文本停滞不动，当按钮释放的时候，将继续移动

代码


package EventDrivenAndAnimation_Practice;

import javafx.animation.PathTransition;
import javafx.animation.Timeline;
import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.paint.Color;
import javafx.scene.text.Text;
import javafx.scene.shape.Line;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;

public class MoveTextAlongLine extends Application {
	public void start(Stage primaryStage) {
		Pane pane = new Pane();

		Text text = new Text("Programming is fun");
		Line line = new Line(-50, 50, 350, 50);
		line.setStroke(Color.WHITE);

		pane.getChildren().addAll(text, line);

		PathTransition pt = new PathTransition();
		pt.setDuration(Duration.millis(5000));
		pt.setPath(line);
		pt.setNode(text);
		pt.setOrientation(PathTransition.OrientationType.ORTHOGONAL_TO_TANGENT);
		pt.setCycleCount(Timeline.INDEFINITE);
		pt.setAutoReverse(true);
		pt.play();

		pane.setOnMousePressed(e -> pt.pause());
		pane.setOnMouseReleased(e -> pt.play());

		text.setOnMousePressed(e -> pt.pause());
		text.setOnMouseReleased(e -> pt.play());

		Scene scene = new Scene(pane, 300, 150);
		primaryStage.setTitle("SwingTheBallo");
		primaryStage.setScene(scene);
		primaryStage.show();

	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

21、显示一个转动的风扇

编写一个程序显示一个转动的风扇，如图所示。Pause、Resume

和 Reverse 按钮用于暂停、继续和反转风扇的转动

代码


package EventDrivenAndAnimation_Practice;

import javafx.animation.KeyFrame;
import javafx.animation.PathTransition;
import javafx.animation.Timeline;
import javafx.application.Application;
import javafx.geometry.Pos;
import javafx.scene.Scene;
import javafx.scene.layout.Pane;
import javafx.scene.layout.BorderPane;
import javafx.scene.layout.HBox;
import javafx.scene.control.Button;
import javafx.scene.paint.Color;
import javafx.scene.text.Text;
import javafx.scene.shape.Line;
import javafx.scene.shape.Arc;
import javafx.scene.shape.ArcType;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;

public class ShowARatatingFan extends Application {
	private FanPane pane = new FanPane();

	public void start(Stage primaryStage) {
		HBox hbox = new HBox();
		hbox.setSpacing(10);
		hbox.setAlignment(Pos.CENTER);

		Button btPause = new Button("Pause");
		Button btResume = new Button("Resume");
		Button btReverse = new Button("Reverse");

		hbox.getChildren().addAll(btPause, btResume, btReverse);

		Timeline timeline = new Timeline(new KeyFrame(Duration.millis(20), e -> pane.resume()));
		timeline.setCycleCount(Timeline.INDEFINITE);
		timeline.play();

		btPause.setOnAction(e -> timeline.pause());
		btResume.setOnAction(e -> timeline.play());
		btReverse.setOnAction(e -> pane.reverse());

		BorderPane borderPane = new BorderPane();
		borderPane.setCenter(pane);
		borderPane.setBottom(hbox);
		BorderPane.setAlignment(hbox, Pos.CENTER);

		Scene scene = new Scene(borderPane);
		primaryStage.setTitle("ShowARatatingFan");
		primaryStage.setScene(scene);
		primaryStage.show();

	}

	class FanPane extends Pane {

		private Circle circle = new Circle(100, 70, 60);;
		private Arc[] arc = new Arc[4];
		private double startAngle = 30;
		private double increment = 5;

		public FanPane() {
			circle.setStroke(Color.BLACK);
			circle.setFill(Color.WHITE);

			getChildren().add(circle);

			for (int i = 0; i < 4; i++) {
				arc[i] = new Arc(100, 70, 50, 50, startAngle + 90 * i, 30);
				arc[i].setType(ArcType.ROUND);
				arc[i].setFill(Color.BLACK);
				getChildren().add(arc[i]);
			}

		}

		public void setAngle(double angle) {
			startAngle = angle;
			for (int i = 0; i < 4; i++)
				arc[i].setStartAngle(startAngle + 90 * i);
		}

		public void resume() {
			setAngle(startAngle + increment);
		}

		public void reverse() {
			increment *= -1;
		}
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

运行结果

22、播放幻灯片

25 张幻灯片都以图像文件（slide0.jpg, slide1.jpg, ....slide24.jpg）的形式存储

在图像目录中. 可以在本书的源代码中下载。每个图像的大小都是 800 x 600 像素。编写一个

Java 应用程序，自动重复显示这些幻灯片。每两秒显示一张幻灯片。幻灯片按顺序显示。当显

示完最后一张幻灯片时，第一张幻灯片重复显示，依此类推。当动画正在播放的时候可以单击

按钮暂停，如果动画当前是暂停的，单击恢复

代码


package EventDrivenAndAnimation_Practice;

import javafx.animation.Animation;
import javafx.animation.FadeTransition;
import javafx.animation.Timeline;
import javafx.animation.KeyFrame;
import javafx.event.*;
import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.image.ImageView;
import javafx.scene.layout.StackPane;
import javafx.scene.paint.Color;
import javafx.scene.shape.Line;
import javafx.scene.image.Image;
import javafx.scene.image.ImageView;
import javafx.scene.text.Text;
import javafx.scene.shape.Circle;
import javafx.stage.Stage;
import javafx.util.Duration;

public class PlayTheSlideShow extends Application {
	public void start(Stage primaryStage) {
		StackPane pane = new StackPane();

		String[] url = new String[53];
		Image[] image = new Image[53];
		ImageView[] imageView = new ImageView[53];

		for (int i = 0; i < 53; i++) {
			url[i] = "/porkerImage/" + (i + 1) + ".jpg";
			image[i] = new Image(url[i]);
			imageView[i] = new ImageView(image[i]);
		}

		pane.getChildren().add(imageView[0]);

		EventHandler eventHandler = e -> {
			for (int i = 0; i < 53; i++)
				if (pane.getChildren().contains(imageView[i])) {
					pane.getChildren().remove(imageView[i]);
					pane.getChildren().add(imageView[i + 1]);
					break;
				}
		};

		Timeline animation = new Timeline(new KeyFrame(Duration.millis(1000), eventHandler));
		animation.setCycleCount(Timeline.INDEFINITE);
		animation.play();

		for (int i = 0; i < 53; i++)
			imageView[i].setOnMouseClicked(e -> {
				if (animation.getStatus() == Animation.Status.PAUSED)
					animation.play();
				else
					animation.pause();
			});
		Scene scene = new Scene(pane, 250, 200);
		primaryStage.setTitle("TimelineDemo");
		primaryStage.setScene(scene);
		primaryStage.show();
	}

	public static void main(String[] args) {
		// TODO Auto-generated method stub
		Application.launch(args);
	}

}

23、几何问題：钟摆

编写一个程序，用动画完成钟摆，如图所示。单击向上箭头 UP 键增加速度，单击向下箭头键 DWON降低速度。单击 S 键停止动画，单击 R 键重新开始

搞了一晚上，就是摆动不起来，算了，先睡了。

相关阅读:
深度学习之基于yolo的体育运动项目姿态估计识别计数系统
 Kubernetes弃用Docker？别误解！这份理论实战都具备的手册还得继续学习呀
 ARM交叉编译
 java面试-zookeeper
ipv6地址概述——配置ipv6
【简说八股】Nginx、GateWay、Ribbon有什么区别？
Python配置与测试利器：Hydra + pytest的完美结合
 代码随想录算法训练营单调栈part03
网络原理---拿捏应用层：HTTP协议
 【机器学习笔记】【决策树】【泰坦尼克号幸存者的预测】
原文地址：https://blog.csdn.net/TaoqiBao_/article/details/127087419

【无标题】

1、选取 4 张卡牌

2、旋转一个四边形

3、移动小球

4、创建一个簡单的计算器

5、 两个消息交替出现

6、使用鼠标改变颜色

7、显示鼠标的位罝

8、使用箭头键画线

9、输入并显示字符串

10、使用键移动圓

11、几何问題：添加或删除点

12、两个可移动的顶点以及它们间的距离

13、几何问题：是否在圆内？

14、几何问題：寻找边界矩形

15、使用鼠标来移动一个矩形

16、游戏：手眼协调

17、动画：来回摆动

18、动画：曲线上的球

19、改变透明度

20、控制一个移动的文本

21、显示一个转动的风扇

22、播放幻灯片

23、几何问題：钟摆

5、两个消息交替出现
