Docker 入门到实战之安装RocketMQ

--- Don`t be the same, be better！---

RocketMQ 是一个队列模型的消息中间件，具有高性能、高可靠、高实时、分布式特点。

具体的描述可参考官网文档：https://rocketmq.apache.org/docs/motivation/

RocketMQ 署

RocketMQ 镜像

docker search rocketmq

一、部署namesrv

namesrv 就类似于消息队列的注册中心，因为rocketmq原生支持集群，所以namesrv就显得很重要。

拉取镜像

首先是拉取镜像，这里拉取的是rocketMQ的核心镜像。这里选取4.4.0版本进行操作。

docker pull rocketmqinc/rocketmq:4.4.0

如果不加版本号，默认拉取的是最新版本：latest。想确认拉取到的镜像的版本的话，可以利用 docker inspect 命令查看。

docker inspect 镜像名/镜像ID


[root@localhost roker]# docker inspect 09bbc30a03b6
[
    {
        "Id": "sha256:09bbc30a03b682786ad205beb772a382d4cecc8a521206d7b3c50e95fb725530",
        "RepoTags": [
            "rocketmqinc/rocketmq:latest"
        ],
        "RepoDigests": [
            "rocketmqinc/rocketmq@sha256:b08556227ad8d169b7927f4c48335877cb10060e6781374ce5a644ea29f6fbe1"
        ],
        "Parent": "",
        "Comment": "",
        "Created": "2019-01-24T09:27:57.997168997Z",
        "Container": "8d5461f9b1304311d307c113cb91261c591b54a820db2333dc24a53f901d3374",
        "ContainerConfig": {
            "Hostname": "a8b39eae818b",
            "Domainname": "",
            "User": "",
            "AttachStdin": false,
            "AttachStdout": false,
            "AttachStderr": false,
            "ExposedPorts": {
                "10909/tcp": {},
                "10911/tcp": {},
                "9876/tcp": {}
            },
            "Tty": false,
            "OpenStdin": false,
            "StdinOnce": false,
            "Env": [
                "PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin",
                "ROCKETMQ_VERSION=4.4.0",
                "ROCKETMQ_HOME=/opt/rocketmq-4.4.0"
            ],
            "Cmd": [
                "/bin/sh",
                "-c",
                "#(nop) WORKDIR /opt/rocketmq-4.4.0/bin"
            ],
            "ArgsEscaped": true,
            "Image": "sha256:cf18f677a66a1ecfa2016959abdd94951ad7a35c89b280f31f39f1a5ab61beb1",
            "Volumes": null,
            "WorkingDir": "/opt/rocketmq-4.4.0/bin",
            "Entrypoint": null,
            "OnBuild": [],
            "Labels": {
                "org.label-schema.build-date": "20181205",
                "org.label-schema.license": "GPLv2",
                "org.label-schema.name": "CentOS Base Image",
                "org.label-schema.schema-version": "1.0",
                "org.label-schema.vendor": "CentOS"
            }
        },
        "DockerVersion": "1.13.1",
        "Author": "",
        "Config": {
            "Hostname": "a8b39eae818b",
            "Domainname": "",
            "User": "",
            "AttachStdin": false,
            "AttachStdout": false,
            "AttachStderr": false,
            "ExposedPorts": {
                "10909/tcp": {},
                "10911/tcp": {},
                "9876/tcp": {}
            },
            "Tty": false,
            "OpenStdin": false,
            "StdinOnce": false,
            "Env": [
                "PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin",
                "ROCKETMQ_VERSION=4.4.0",
                "ROCKETMQ_HOME=/opt/rocketmq-4.4.0"
            ],
            "Cmd": [
                "/bin/bash"
            ],
            "ArgsEscaped": true,
            "Image": "sha256:cf18f677a66a1ecfa2016959abdd94951ad7a35c89b280f31f39f1a5ab61beb1",
            "Volumes": null,
            "WorkingDir": "/opt/rocketmq-4.4.0/bin",
            "Entrypoint": null,
            "OnBuild": [],
            "Labels": {
                "org.label-schema.build-date": "20181205",
                "org.label-schema.license": "GPLv2",
                "org.label-schema.name": "CentOS Base Image",
                "org.label-schema.schema-version": "1.0",
                "org.label-schema.vendor": "CentOS"
            }
        },
        "Architecture": "amd64",
        "Os": "linux",
        "Size": 380393601,
        "VirtualSize": 380393601,
        "GraphDriver": {
            "Data": {
                "LowerDir": "/var/lib/docker/overlay2/be88140e2ac3afee73aea9c896483957b551f7ce26a59654a132c9369a71ef42/diff:/var/lib/docker/overlay2/705f8e8991114ea481b858c81fbb509926bdc0c39a51c2740046deceee406683/diff:/var/lib/docker/overlay2/dc8719daa823b125ef5710e4ecc3b009b06a8075376a1f0782ca8efbb23bf09f/diff:/var/lib/docker/overlay2/103f52afcf6b6c1c8edf0a98bd3b2e0c0242ed9990be9ed7c81113abf6812366/diff:/var/lib/docker/overlay2/e2e0be6dd3bbec94da46873708347d706dc82bb448fac0a1b98ce8279df397db/diff:/var/lib/docker/overlay2/5eb13e209a54015521756f4c8568100a01be13f0b73410f99abdbb7b6afcc4f3/diff:/var/lib/docker/overlay2/e90ea65557175e5555810565c14e4938772870a4300b27e1aeb79f4f31868bed/diff",
                "MergedDir": "/var/lib/docker/overlay2/de0928e884167c9933c1561dc721a805c3cddb1425c021256807ab88a4da572f/merged",
                "UpperDir": "/var/lib/docker/overlay2/de0928e884167c9933c1561dc721a805c3cddb1425c021256807ab88a4da572f/diff",
                "WorkDir": "/var/lib/docker/overlay2/de0928e884167c9933c1561dc721a805c3cddb1425c021256807ab88a4da572f/work"
            },
            "Name": "overlay2"
        },
        "RootFS": {
            "Type": "layers",
            "Layers": [
                "sha256:071d8bd765171080d01682844524be57ac9883e53079b6ac66707e192ea25956",
                "sha256:f3e23290ed2c15b97180d39a7fbf55236e5e750aae44e08c054b90ffd371ddba",
                "sha256:edd13d457cc130b61e1d96448502d0c90baf846abd04f1b76a0c33e4d90cd907",
                "sha256:bd01a461b66b9da34ff5efb91cb15f3b5fe7ecc7e0e069786517b12240ccc37e",
                "sha256:a42c26b79bf8dcf87557460a20448a7fd9a0725bcb76d3ba0dc0c2a955cccaf5",
                "sha256:3dd012a176dfd1a397f84eae13d07505bccaffd74db3b1a5d4698fecbfede8a5",
                "sha256:5ab4fc027c7ede59acb94f10e9292f88ee5096c112c9375f69aca6b152aada6b",
                "sha256:1e990feb9b9d79d57f3b48ed803a56cfeced51347f72d450c303e5efa86f7003"
            ]
        },
        "Metadata": {
            "LastTagTime": "0001-01-01T00:00:00Z"
        }
    }
]

其中 ROCKETMQ_VERSION=4.4.0 说明当前最新版本为4.4.0。

启动namesrv

启动过程也很简单，主要是docker的一些参数和配置指定。启动命令如下：

docker run -d -p 9876:9876 \
--name rmqnamesrv \
--restart=always \
-v /data/docker/rocketmq/data/namesrv/logs:/root/logs \
-v /data/docker/rocketmq/namesrv/store:/root/store \
-e "MAX_POSSIBLE_HEAP=100000000" \
rocketmqinc/rocketmq:latest \
sh mqnamesrv

命令详解：


# 后台运行，并映射端口
docker run -d -p 9876:9876 \
# 设置容器名称
--name rmqnamesrv \
# 设置重启策略
--restart=always \
# 映射日志文件夹（前面的为本地路径）
-v /data/docker/rocketmq/data/namesrv/logs:/root/logs \
# 映射书籍存在文件夹（同上）
-v /data/docker/rocketmq/namesrv/store:/root/store \
# 指定环境变量
-e "MAX_POSSIBLE_HEAP=100000000" \
# 指定镜像版本，这里建议指定具体版本，否则在和java交互的时候会报错，目前最新版本是4.4.0，所以maven的依赖也必须对应，否则会报错
rocketmqinc/rocketmq:latest \
# 启动命令
sh mqnamesrv

查看容器：

二、部署broker

由于broker和namesrv是同一个镜像，所以这里不需要再拉取其他镜像。

创建broker配置

除了最后两行配置，其他的配置都是系统默认的，具体说明可以参考官方文档。

mkdir -p /data/docker/rocketmq/conf

touch broker.conf

vi broker.conf


# broker集群名称
brokerClusterNam = DefaultCluster
# broker节点名称
brokerName = broker-a
# broker节点id
brokerId = 0
# 删除条件？这个还不清楚用途，后续研究下
deleteWhen = 04
# 文件保留时间（单位小时），默认为3天
fileReservedTime = 48
# broker角色
brokerRole = ASYNC_MASTER
# 磁盘同步方式：同步，异步
flushDiskType = ASYNC_FLUSH
# 类似注册中心
namesrvAddr=192.168.10.128:9876
# 当前broker监听的IP(主)
brokerIP1 = 192.168.10.128

注：若忽略此步，可能在下步启动broker时出现如下问题时


docker: Error response from daemon: failed to create shim task:
OCI runtime create failed: runc create failed: unable to start container process: error during container init:
error mounting "/data/docker/rocketmq/conf/broker.conf" to rootfs at "/opt/rocketmq-4.4.0/conf/broker.conf": mount /data/docker/rocketmq/conf/broker.conf:/opt/rocketmq-4.4.0/conf/broker.conf (via /proc/self/fd/6),
flags: 0x5000: not a directory: unknown: Are you trying to mount a directory onto a file (or vice-versa)?
Check if the specified host path exists and is the expected type.

启动broker

这里的启动命令最核心的其实就是最后sh操作，这里制定了配置文件的路径。

docker run -d \
-p 10911:10911 \
-p 10909:10909 \
--name rmqbroker \
--restart=always \
-v /data/docker/rocketmq/data/broker/logs:/root/logs \
-v /data/docker/rocketmq/data/broker/store:/root/store \
-v /data/docker/rocketmq/conf/broker.conf:/opt/rocketmq-4.4.0/conf/broker.conf \
--link rmqnamesrv:namesrv \
-e "NAMESRV_ADDR=namesrv:9876" \
-e "MAX_POSSIBLE_HEAP=200000000" rocketmqinc/rocketmq:latest \
sh mqbroker -c /opt/rocketmq-4.4.0/conf/broker.conf

命令详解：


# 后台运行
 docker run -d \
 # 映射端口
-p 10911:10911 \
# 映射端口
-p 10909:10909 \
# 容器名称
--name rmqbroker \
# 重启策略
--restart=always \
# 映射日志路径
-v /data/docker/rocketmq/data/broker/logs:/root/logs \
# 映射文件存储路径
-v /data/docker/rocketmq/data/broker/store:/root/store \
# 映射配置文件
-v /data/docker/rocketmq/conf/broker.conf:/opt/rocketmq-4.4.0/conf/broker.conf \
# 链接namesrv
--link rmqnamesrv:namesrv \
# 指定环境设置
-e "NAMESRV_ADDR=namesrv:9876" \
# 指定环境设置，指定镜像
-e "MAX_POSSIBLE_HEAP=200000000" rocketmqinc/rocketmq:latest \
# 启动命令（指定配置启动）
sh mqbroker -c /opt/rocketmq-4.4.0/conf/broker.conf

查看容器：

由于这里我们把rocketmq的日志映射到了本机目录，所以我们可以直接通过tail查看broker的启动日志，比如broker.log:

tail -f /data/docker/rocketmq/data/broker/logs/rocketmqlogs/broker.log

当然，你也可以通过docker exec命令的方式进入容器内查看日志，当然就是没有上面这种方式方便。

三、安装console

console是rocketmq的扩展组件，console组件提供了图形化的界面，便于我们管理和监控rocketmq，界面截图如下：

官方文档：

RocketMQ Console

拉取镜像

默认拉取最新版本镜像：

docker pull styletang/rocketmq-console-ng

启动console

启动命令也很简单，只是指定rocketmq的namesrv的地址，除了端口有修改，其他直接复制官方文档

docker run -e "JAVA_OPTS=-Drocketmq.namesrv.addr=192.168.10.128:9876 -Dcom.rocketmq.sendMessageWithVIPChannel=false" -p 8000:8080 -t styletang/rocketmq-console-ng

启动成功后直接访问我们配置的端口，示例地址：http://192.168.10.128:8000 ：

- END -

至此，我们可以在实际项目中引入RocketMQ进行实战了。
