hibernate源码（1）--- schema创建

sessionFactory

配置项：

hibernate的核心是sessionFactory，那我们看看如何构建session Factory。
参考官网：

plugins {
    id("java")
}
group = "com.atai.hibernatespy"
version = "1.0-SNAPSHOT"
repositories {
    mavenCentral()
}
dependencies {
    // the GOAT ORM
    implementation("org.hibernate.orm:hibernate-core:6.3.0.Final")
    // Hibernate Validator)
    implementation("org.hibernate.validator:hibernate-validator:8.0.0.Final")
    implementation("org.glassfish:jakarta.el:4.0.2")
    // Agroal connection pool)
    implementation("org.hibernate.orm:hibernate-agroal:6.3.0.Final")
    implementation("io.agroal:agroal-pool:2.1")
    // logging via Log4j)
    implementation("org.apache.logging.log4j:log4j-core:2.20.0")
    //JPA Metamodel Generator)
    annotationProcessor("org.hibernate.orm:hibernate-jpamodelgen:6.3.0.Final")
    runtimeOnly("com.h2database:h2:2.1.214")
// Compile-time checking for HQL
    //implementation 'org.hibernate : query-validator: 2.O-SNAPSHOT'//annotationProcessor 'org.hibernate: query-validator: 2.O-SNAPSHOT'
// H2 database
//    runtimeonly( 'com.h2database:h2:2.1.214')
    testImplementation(platform("org.junit:junit-bom:5.9.1"))
    testImplementation("org.junit.jupiter:junit-jupiter")
}
tasks.test {
    useJUnitPlatform()
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

package org.example;

import com.atai.entity.Book;
import org.hibernate.cfg.Configuration;

import static java.lang.Boolean.TRUE;
import static java.lang.System.out;
import static org.hibernate.cfg.JdbcSettings.*;
import static org.hibernate.cfg.JdbcSettings.HIGHLIGHT_SQL;

public class Main {
    public static void main(String[] args) {
        var sessionFactory = new Configuration()
                .addAnnotatedClass(Book.class)
                .setProperty(URL, "jdbc:h2:mem:db1")
                .setProperty(USER, "sa")
                .setProperty(PASS, "")
                // use Agroal connection pool
                .setProperty("hibernate.agroal.maxSize", "20")//display sQL in console
                .setProperty(SHOW_SQL, TRUE.toString())
                .setProperty(FORMAT_SQL, TRUE.toString())
                .setProperty(HIGHLIGHT_SQL, TRUE.toString()).buildSessionFactory();
        // export the inferred database schema
        sessionFactory.getSchemaManager().exportMappedObjects(true);
        // persist an entity
        sessionFactory.inTransaction(session -> {
            session.persist(new Book("9781932394153", "Hibernate in Action"));
        });
        // query data using HQL
        sessionFactory.inSession(session -> {
            out.println(session.createSelectionQuery(" select isbn||': '||title from Book").getSingleResult());
        });
        // query data using criteria API
        sessionFactory.inSession(session -> {
            var builder = sessionFactory.getCriteriaBuilder();
            var query = builder.createQuery(String.class);
            var book = query.from(Book.class);
            query.select(builder.concat(builder.concat(book.get("isbn"), builder.literal(": ")), book.get("title")));
            out.println(session.createSelectionQuery(query).getSingleResult());
        });
    }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

可以通过Configuration来进行创建，参数配置在property中，buildSessionFactory（） 创建出sf。
有了sf，即可以连接数据库处理。

schema相关

前面的例子中，已经有了比较好的实例，通过sf的schemaManager创建：

sessionFactory.getSchemaManager().exportMappedObjects(true);

public interface SchemaManager {
	/**
	 * Export database objects mapped by Hibernate entities.
	 *

	 * Programmatic way to run {@link org.hibernate.tool.schema.spi.SchemaCreator}.
	 *
	 * @param createSchemas if {@code true}, attempt to create schemas,
	 *                      otherwise, assume the schemas already exist
	 */
	void exportMappedObjects(boolean createSchemas);

	/**
	 * Drop database objects mapped by Hibernate entities, undoing the
	 * {@linkplain #exportMappedObjects(boolean) previous export}.
	 *

	 * Programmatic way to run {@link org.hibernate.tool.schema.spi.SchemaDropper}.
	 *
	 * @param dropSchemas if {@code true}, drop schemas,
	 *                    otherwise, leave them be
	 */
	void dropMappedObjects(boolean dropSchemas);

	/**
	 * Validate that the database objects mapped by Hibernate entities
	 * have the expected definitions.
	 *

	 * Programmatic way to run {@link org.hibernate.tool.schema.spi.SchemaValidator}.
	 */
	void validateMappedObjects();

	/**
	 * Truncate the database tables mapped by Hibernate entities, and
	 * then re-import initial data from any configured
	 * {@linkplain org.hibernate.cfg.AvailableSettings#JAKARTA_HBM2DDL_LOAD_SCRIPT_SOURCE
	 * load script}.
	 *

	 * Programmatic way to run {@link org.hibernate.tool.schema.spi.SchemaTruncator}.
	 */
	void truncateMappedObjects();
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

另一个与schema关系较大的类就是：SchemaManagementToolCoordinator

   List<Class> classes = Arrays.asList(AccessconfigEntity.class);
                Properties p = new Properties();
                // 数据库方言，最终输出的方言
                p.put(AvailableSettings.DIALECT, MySQL5InnoDBDialect.class.getName());
                // 自动执行的动作
                p.put(AvailableSettings.HBM2DDL_AUTO, ddlAuto);
                // 分隔符，默认为空
                p.put(AvailableSettings.HBM2DDL_DELIMITER, ";");
                // 是否展示SQL
                p.put(AvailableSettings.SHOW_SQL, true);
                p.put("hibernate.connection.driver_class", dataSource.getDriverClassName());
                p.put("hibernate.connection.url", urlTena);
                p.put("hibernate.connection.username", dataSource.getUsername());
                p.put("hibernate.connection.password", dataSource.getPassword());
                // 是否使用默认的jdbc元数据，默认为true，读取项目自身的元数据
                p.put("hibernate.temp.use_jdbc_metadata_defaults", true);
//                p.put("hibernate.temp.use_jdbc_metadata_defaults", false);
                ConfigurationHelper.resolvePlaceHolders(p);
                ServiceRegistry registry = new StandardServiceRegistryBuilder()
                        .applySettings(p)
                        .build();
//                registry.get
                Map settings = registry.getService(ConfigurationService.class).getSettings();
                MetadataSources metadataSources = new MetadataSources(registry);
                entities.forEach(new Consumer<EntityType<?>>() {
                    @Override
                    public void accept(EntityType<?> entityType) {
                        metadataSources.addAnnotatedClass(entityType.getJavaType());
                    }
                });
                classes.forEach(metadataSources::addAnnotatedClass);
                Metadata metadata = metadataSources.buildMetadata();
                HashMap properties = new HashMap<>();
                properties.putAll(registry.getService(ConfigurationService.class).getSettings());
                SchemaManagementToolCoordinator.process(metadata, registry, settings, null);
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35

如果做代码跟踪，就会发现是否使用默认的use_jdbc_metadata_defaults 配置项将会建立连接，获取数据库的表信息。

SchemaExport

schemaexport是另一个与schema相关的类，可以控制台输出，脚本文件输出与数据库创建：

        Configuration cfn = new Configuration();
        cfn.setProperty("hibernate.connection.driver_class", "com.mysql.jdbc.Driver");
        cfn.setProperty("hibernate.connection.url", "jdbc:mysql://10.110.87.204:3306/corps?useOldAliasMetadataBehavior=true&serverTimezone=GMT%2B8&useUnicode=true&characterEncoding=UTF-8&useSSL=false&nullCatalogMeansCurrent=true");
        cfn.setProperty("hibernate.connection.username", "root");
        cfn.setProperty("hibernate.connection.password", "liugeba?68");
        cfn.setProperty("hibernate.dialect", "org.hibernate.dialect.MySQL5InnoDBDialect");
        cfn.configure();
        ServiceRegistry registry = new StandardServiceRegistryBuilder().applySettings(cfn.getProperties()).build();
//        System.out.println(cfn.toString());
//
//        ServiceRegistry registry = new StandardServiceRegistryBuilder().configure().build();
//        registry.
        Metadata metadata = new MetadataSources(registry).buildMetadata();
        SchemaExport export = new SchemaExport();
        export.create(EnumSet.of(TargetType.DATABASE), metadata);
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

实际操作的也就是下面的几个类：
