Flink系列文档-(YY07)-Flink编程API-process function

1 概述

process function相对于前文所述的map、flatmap、filter算子来说，最大的区别是其让开发人员对数据的处理逻辑拥有更大的自由度；同时，ProcessFunction 继承了RichFunction，因而具备了getRuntimeContext() ，open() ，close()等方法；

在不同类型的datastream上，（比如keyed stream、windowedStream、ConnectedStream等），应用process function时，flink提供了大量不同类型的process function，让其针对不同的datastream拥有更具针对性的功能；

1. ProcessFunction （普通DataStream上调process时）
2. KeyedProcessFunction （KeyedStream上调process时）
3. ProcessWindowFunction（WindowedStream上调process时）
4. ProcessAllWindowFunction（AllWindowedStream上调process时）
5. CoProcessFuntion （ConnectedStreams上调process时）
6. ProcessJoinFunction （JoinedStreams上调process时）
7. BroadcastProcessFunction （BroadCastConnectedStreams上调process时）
8. KeyedBroadcastProcessFunction（KeyedBroadCastConnectedStreams上调process时）

  各种算子运算后所生成的datastream类型，及各种datastream类型之间的互相转换关系

在不同类型的 数据流上，调用process算子时，所需要传入的ProcessFunction也会有不同

2 示例代码

数据源头调用方法

package com.blok;

import com.mysql.cj.jdbc.MysqlXADataSource;
import com.pojo.BigYY;
import com.yao.yao.base01.MySource;
import com.yao.yao.base01.beans.DaYao;
import org.apache.flink.api.common.functions.RuntimeContext;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.connector.jdbc.*;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.ProcessFunction;
import org.apache.flink.streaming.api.functions.sink.SinkFunction;
import org.apache.flink.util.Collector;
import org.apache.flink.util.function.SerializableSupplier;

import javax.sql.XADataSource;
import java.sql.PreparedStatement;
import java.sql.SQLException;

/**
 * @Date: 22.11.11
 * @Author: Hang.Nian.YY
 * @qq: 598196583
 * @Tips: 学大数据 ,到多易教育
 * @Description:
 */
public class _19Base_API_Process_Function {

    public static void main(String[] args) throws Exception {
        Configuration conf = new Configuration();
        conf.setInteger("rest.port", 8888);
        StreamExecutionEnvironment see = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(conf);
        see.setParallelism(1);

        DataStreamSource ds = see.socketTextStream("linux01", 8899);
        /**
         *    壹
         * 源头数据  调用process方法
         */
        ds.process(new ProcessFunction() { // 泛型1输入数据类型  泛型2输出数据类型
            /**
             *每来一条数据  方法被调用一次
             * ctx 上下文对象  可以操作测流
             * out 用于输出
             *
             */
            @Override
            public void processElement(String value, ProcessFunction.Context ctx, Collector out) throws Exception {
                String[] arr = value.split(",");
                out.collect(new BigYY(arr[0], arr[1], arr[2], Double.parseDouble(arr[3])));
            }

            /**
             * 生命周期方法
             * @param parameters The configuration containing the parameters attached to the contract.
             * @throws Exception
             */
            @Override
            public void open(Configuration parameters) throws Exception {
                RuntimeContext runtimeContext = getRuntimeContext();
                // 获取程序运行的task信息
                runtimeContext.getTaskNameWithSubtasks();
                runtimeContext.getTaskName();
                runtimeContext.getIndexOfThisSubtask();
                // 获取状态对象   获取累加器等
                //  runtimeContext.getBroadcastVariable() ;
                super.open(parameters);
            }

            @Override
            public void close() throws Exception {
                super.close();
            }
        });


    }
}

keyBy后调用方法

package com.blok;

import com.mysql.cj.jdbc.MysqlXADataSource;
import com.pojo.BigYY;
import com.yao.yao.base01.MySource;
import com.yao.yao.base01.beans.DaYao;
import org.apache.flink.api.common.functions.RuntimeContext;
import org.apache.flink.api.java.functions.KeySelector;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.connector.jdbc.*;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.datastream.KeyedStream;
import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
import org.apache.flink.streaming.api.functions.ProcessFunction;
import org.apache.flink.streaming.api.functions.sink.SinkFunction;
import org.apache.flink.util.Collector;
import org.apache.flink.util.function.SerializableSupplier;

import javax.sql.XADataSource;
import java.sql.PreparedStatement;
import java.sql.SQLException;

/**
 * @Date: 22.11.11
 * @Author: Hang.Nian.YY
 * @qq: 598196583
 * @Tips: 学大数据 ,到多易教育
 * @Description:
 */
public class _19Base_API_Process_Function {

    public static void main(String[] args) throws Exception {
        Configuration conf = new Configuration();
        conf.setInteger("rest.port", 8888);
        StreamExecutionEnvironment see = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(conf);
        see.setParallelism(1);

        DataStreamSource ds = see.socketTextStream("linux01", 8899);
        /**
         *    壹
         * 源头数据  调用process方法
         */
        SingleOutputStreamOperator ds2 = ds.process(new ProcessFunction() { // 泛型1输入数据类型  泛型2输出数据类型
            /**
             *每来一条数据  方法被调用一次
             * ctx 上下文对象  可以操作测流
             * out 用于输出
             *
             */
            @Override
            public void processElement(String value, ProcessFunction.Context ctx, Collector out) throws Exception {
                String[] arr = value.split(",");
                out.collect(new BigYY(arr[0], arr[1], arr[2], Double.parseDouble(arr[3])));
            }

            /**
             * 生命周期方法
             * @param parameters The configuration containing the parameters attached to the contract.
             * @throws Exception
             */
            @Override
            public void open(Configuration parameters) throws Exception {
                RuntimeContext runtimeContext = getRuntimeContext();
                // 获取程序运行的task信息
                runtimeContext.getTaskNameWithSubtasks();
                runtimeContext.getTaskName();
                runtimeContext.getIndexOfThisSubtask();
                // 获取状态对象   获取累加器等
                //  runtimeContext.getBroadcastVariable() ;
                super.open(parameters);
            }

            @Override
            public void close() throws Exception {
                super.close();
            }
        });

        /**
         * 贰
         * 处理数据源  , 将数据封装成指定的数据格式  然后对数据进行分组
         * 在keyBy后使用process方法处理数据
         */
        // 将数据按照城市分组
        ds2.keyBy(BigYY::getCity);
        KeyedStream keyed = ds2.keyBy(new KeySelector() {
            @Override
            public String getKey(BigYY value) throws Exception {
                return value.getCity();
            }
        });

        //   KeyedProcessFunction
        // 泛型1  流的key的数据类型  泛型2 输入的数据类型  泛型3  输出的数据类型
        keyed.process(new KeyedProcessFunction() {

            // 生命周期方法
            @Override
            public void open(Configuration parameters) throws Exception {
                RuntimeContext runtimeContext = getRuntimeContext();
                super.open(parameters);
            }

            // 数据处理的方法
            @Override
            public void processElement(BigYY value, KeyedProcessFunction.Context ctx, Collector out) throws Exception {

            }

            // 生命周期方法
            @Override
            public void close() throws Exception {
                super.close();
            }
        });

        //  ProcessFunction  这方法已经过期
        keyed.process(new ProcessFunction() {
            @Override
            public void processElement(BigYY value, ProcessFunction.Context ctx, Collector out) throws Exception {

            }
        });


    }
}

开窗后调用方法

package com.blok;

import com.mysql.cj.jdbc.MysqlXADataSource;
import com.pojo.BigYY;
import com.yao.yao.base01.MySource;
import com.yao.yao.base01.beans.DaYao;
import org.apache.flink.api.common.functions.RuntimeContext;
import org.apache.flink.api.java.functions.KeySelector;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.connector.jdbc.*;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.datastream.KeyedStream;
import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
import org.apache.flink.streaming.api.functions.ProcessFunction;
import org.apache.flink.streaming.api.functions.sink.SinkFunction;
import org.apache.flink.streaming.api.functions.windowing.ProcessAllWindowFunction;
import org.apache.flink.streaming.api.scala.function.ProcessWindowFunction;
import org.apache.flink.streaming.api.windowing.assigners.TumblingProcessingTimeWindows;
import org.apache.flink.streaming.api.windowing.time.Time;
import org.apache.flink.streaming.api.windowing.windows.GlobalWindow;
import org.apache.flink.streaming.api.windowing.windows.TimeWindow;
import org.apache.flink.util.Collector;
import org.apache.flink.util.function.SerializableSupplier;

import javax.sql.XADataSource;
import java.sql.PreparedStatement;
import java.sql.SQLException;

/**
 * @Date: 22.11.11
 * @Author: Hang.Nian.YY
 * @qq: 598196583
 * @Tips: 学大数据 ,到多易教育
 * @Description:
 */
public class _19Base_API_Process_Function {

    public static void main(String[] args) throws Exception {
        Configuration conf = new Configuration();
        conf.setInteger("rest.port", 8888);
        StreamExecutionEnvironment see = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(conf);
        see.setParallelism(1);

        DataStreamSource ds = see.socketTextStream("linux01", 8899);
        /**
         *    壹
         * 源头数据  调用process方法
         */
        SingleOutputStreamOperator ds2 = ds.process(new ProcessFunction() { // 泛型1输入数据类型  泛型2输出数据类型
            /**
             *每来一条数据  方法被调用一次
             * ctx 上下文对象  可以操作测流
             * out 用于输出
             *
             */
            @Override
            public void processElement(String value, ProcessFunction.Context ctx, Collector out) throws Exception {
                String[] arr = value.split(",");
                out.collect(new BigYY(arr[0], arr[1], arr[2], Double.parseDouble(arr[3])));
            }

            /**
             * 生命周期方法
             * @param parameters The configuration containing the parameters attached to the contract.
             * @throws Exception
             */
            @Override
            public void open(Configuration parameters) throws Exception {
                RuntimeContext runtimeContext = getRuntimeContext();
                // 获取程序运行的task信息
                runtimeContext.getTaskNameWithSubtasks();
                runtimeContext.getTaskName();
                runtimeContext.getIndexOfThisSubtask();
                // 获取状态对象   获取累加器等
                //  runtimeContext.getBroadcastVariable() ;
                super.open(parameters);
            }

            @Override
            public void close() throws Exception {
                super.close();
            }
        });

        /**
         * 叁
         * 开窗后调用 process方法
         * 依然后生命周期方法
         * 获取运行时环境的方法
         */
        ds2
                .windowAll(TumblingProcessingTimeWindows.of(Time.seconds(10))) // 滚动窗口
                .process(new ProcessAllWindowFunction() {
                    @Override
                    public void process(ProcessAllWindowFunction.Context context, Iterable elements, Collector out) throws Exception {

                    }
                });

        ds2.countWindowAll(10).process(new ProcessAllWindowFunction() {
            @Override
            public void process(ProcessAllWindowFunction.Context context, Iterable elements, Collector out) throws Exception {

            }
        });


    }
}

开窗后才有的apply方法

/**
 * @Date: 22.11.11
 * @Author: Hang.Nian.YY
 * @qq: 598196583
 * @Tips: 学大数据 ,到多易教育
 * @Description:
 */
public class _19Base_API_Process_Function {

    public static void main(String[] args) throws Exception {
        Configuration conf = new Configuration();
        conf.setInteger("rest.port", 8888);
        StreamExecutionEnvironment see = StreamExecutionEnvironment.createLocalEnvironmentWithWebUI(conf);
        see.setParallelism(1);

        DataStreamSource ds = see.socketTextStream("linux01", 8899);
        /**
         *    壹
         * 源头数据  调用process方法
         */
        SingleOutputStreamOperator ds2 = ds.process(new ProcessFunction() { // 泛型1输入数据类型  泛型2输出数据类型
            /**
             *每来一条数据  方法被调用一次
             * ctx 上下文对象  可以操作测流
             * out 用于输出
             *
             */
            @Override
            public void processElement(String value, ProcessFunction.Context ctx, Collector out) throws Exception {
                String[] arr = value.split(",");
                out.collect(new BigYY(arr[0], arr[1], arr[2], Double.parseDouble(arr[3])));
            }

            /**
             * 生命周期方法
             * @param parameters The configuration containing the parameters attached to the contract.
             * @throws Exception
             */
            @Override
            public void open(Configuration parameters) throws Exception {
                RuntimeContext runtimeContext = getRuntimeContext();
                // 获取程序运行的task信息
                runtimeContext.getTaskNameWithSubtasks();
                runtimeContext.getTaskName();
                runtimeContext.getIndexOfThisSubtask();
                // 获取状态对象   获取累加器等
                //  runtimeContext.getBroadcastVariable() ;
                super.open(parameters);
            }

            @Override
            public void close() throws Exception {
                super.close();
            }
        });

        /**
         * 叁
         * 开窗后调用 apply
         * 没有生命周期方法
         * 不能运行时环境的方法
         */
        ds2
                .windowAll(TumblingProcessingTimeWindows.of(Time.seconds(10))) // 滚动窗口
                .apply(new AllWindowFunction() {
                    //窗口触发一次  调用一次这个方法
                    //values 迭代本窗口中所有数据的迭代器
                    @Override
                    public void apply(TimeWindow window, Iterable values, Collector out) throws Exception {
                        double sum = 0d;
                        for (BigYY by : values) {

                            double appearance = by.getAppearance();
                            sum += appearance;
                        }
                        out.collect(sum);
                    }
                });


    }
}
